KEB combivert R6-S Applications Manual

Page 3.1 - 4 COMBIVERT R6-S © KEB, 2008-02
Parameter overview
Parameter Addr. R P E Lower limit Upper limit Default Step Unity Reference
do.02 condition 1 0C02h rw p E 0 92 3 1 --- 3.2-8, 3.4-15
do.03 condition 1 0C03h rw p E 0 92 3 1 --- 3.2-8, 3.4-15
do.04 condition 1 0C04h rw p E 0 92 3 1 --- 3.2-8, 3.4-15
do.05 condition 1 0C05h rw p E 0 92 3 1 --- 3.2-8, 3.4-15
do.06 condition 1 0C06h rw p E 0 92 3 1 --- 3.2-8, 3.4-15
do.07 condition 7 0C07h rw p E 0 92 0 1 --- 3.2-8,3.4-12,3.4-13, 3.4-14
do.08 inv.cond.forag0 0C08h rw p E 0 255 0 1 --- 3.4-12, 3.4-15
do.09 inv.cond.forag1 0C09h rw p E 0 255 0 1 --- 3.4-15
do.15 inv.cond.forag7 0C0Fh rw p E 0 255 0 1 --- 3.4-12, 3.4-15
do.16 cond.select.forag0 0C10h rw p E 0 255 1 1 --- 3.4-12, 3.4-15
do.23 cond.select.forag7 0C17h rw p E 0 255 128 1 --- 3.4-12, 3.4-15
do.24 ANDconn.forags 0C18h rw p E 0 255 0 1 --- 3.4-12, 3.4-15, 3.4-16
do.25 inv.agsforO1 0C19h rw p E 0 255 0 1 --- 3.4-12, 3.4-16
do.28 inv.agsforR2 0C1Ch rw p E 0 255 0 1 --- 3.4-3
do.32 inv.agsforOD 0C20h rw p E 0 255 0 1 --- 3.4-16
do.33 agselect.forO1 0C21h rw p E 0 255 1 1 --- 3.4-12, 3.4-17
do.36 agselect.forR2 0C24h rw p E 0 255 8 1 --- 3.4-3
do.40 agselect.forOD 0C28h rw p E 0 255 128 1 --- 3.4-16, 3.4-17
do.41 AND conn. for outputs 0C29h rw p E 0 255 0 1 --- 3.4-12, 3.4-17
do.42 inverted outputs 0C2Ah rw p E 0 255 0 1 --- 3.4-12, 3.4-17
do.43 SB0ltertime 0C2Bh rw p --- 0 1000 0 1 ms 3.4-12
do.44 SB1ltertime 0C2Ch rw p --- 0 1000 0 1 ms 3.4-12,
do.51 hardw. output allocation 0C33h rw p E 0 255 228 1 ---
3.2-11, 3.2-17, 3.4-12,
3.4-18
Fr.01 copy parameter set 0901h rw p E -9 7 0 1 --- 3.7-2, 3.7-3, 3.7-4, 3.7-5
Fr.02 parameter set source 0902h rw np E 0 5 0 1 ---
3.2-19, 3.7-3, 3.7-6, 3.7-8,
3.7-9
Fr.03 parameter set lock 0903h rw np E 0 255 0 1 --- 3.6-6, 3.7-6, 3.7-9
Fr.04 parameter set setting 0904h rw np E 0 7 0 1 --- 3.7-6, 3.7-7
Fr.05 set activation delay 0905h rw p --- 0,00 32,00 0,00 0,01 s 3.7-10
Fr.06 set deactivation delay 0906h rw p --- 0,00 32,00 0,00 0,01 s 3.7-10
Fr.07 parameter set input sel. 0907h rw np E 0 4095 0 1 --- 3.4-9, 3.7-7, 3.7-8
Fr.09 bus parameter set 0909h rw np --- -1:actset 7 0 1 --- 3.7-3, 3.7-5, 3.9-4
Fr.11 reset > set 0 input sel. 090Bh rw np E 0 4095 0 1 --- 3.4-9, 3.7-9
In.00 inverter type 0E00h
ro np --- 0 65535 0 1 hex 3.2 - 4, 3.2-12
In.01 DC rated current 0E01h ro np --- 0,0 6553,5 0,0 0,1 A 3.2 - 4, 3.2-12
In.06 software version 0E06h ro np --- SW SW SW 0,01 --- 3.2 - 4, 3.2-12
In.07 software date 0E07h ro np --- SW SW SW 0,1 --- 3.2 - 4, 3.2-12
In.10 serial no. (date) 0E0Ah ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13, 3.7-3
In.11 serial no. (count) 0E0Bh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.12 serial no. (AB high) 0E0Ch ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.13 serial no. (AB low) 0E0Dh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.14 customer no. high 0E0Eh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.15 customer no. low 0E0Fh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.16 QS no. 0E10h ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.22 user parameter 1 0E16h rw np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.23 user parameter 2 0E17h rw np --- 0 65535 0 1 --- 3.2 - 4, 3.2-13
In.24 last error 0E18h ro p E 0 255 0 1 --- 3.2 - 4, 3.2-13, 3.7-3
In.25 error diagnosis 0E19h ro p --- 0 65535 0 1 hex 3.2 - 4, 3.2-14
In.26 E.OC error counter 0E1Ah ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-14
In.27 E.OL error counter 0E1Bh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-14
In.28 E.OP error counter 0E1Ch ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-14
In.29 E.OH error counter 0E1Dh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-14
In.30 E.OHI error counter 0E1Eh ro np --- 0 65535 0 1 --- 3.2 - 4, 3.2-14
LE.00 comparison 0 0D00h rw p --- -10737418,24 10737418,23 0,00 0.01 --- 3.4-14, 3.8-3, 3.8-6, 3.9-6
LE.07 comparison 7 0D07h rw p --- -10737418,24 10737418,23 0,00 0.01 --- 3.4-14, 3.8-6
LE.08 hysteresis 0 0D08h rw p --- 0,00 300,00 0,00 0.01 --- 3.4-15
LE.09 hysteresis 1 0D09h rw p --- 0,00 300,00 0,00 0.01 --- 3.4-15
LE.15 hysteresis 7 0D0Fh rw p --- 0,00 300,00 0,00 0.01 --- 3.4-14, 3.4-15
LE.17 timer 1 start inp. sel. 0D11h rw np E 0 4095 0 1 ---
3.2-10, 3.4-9, 3.7-3, 3.8-3,
3.8-4, 3.8-5
LE.18 timer 1 start condition 0D12h rw np E 0 15 0 1 --- 3.8-3, 3.8-4
LE.19 timer 1 reset inp. sel. 0D13h rw np E 0 4095 0 1 --- 3.4-9, 3.8-3, 3.8-5
LE.20 timer 1 reset condition 0D14h rw np E 0 31 16 1 --- 3.8-3, 3.8-6
LE.21 timer 1 mode 0D15h rw np --- 0 63 0 1 --- 3.2-10, 3.8-3, 3.8-4, 3.8-5
LE.22 timer 2 start inp. sel. 0D16h rw np E 0 4095 0 1 ---
3.2-10, 3.4-9, 3.8-3, 3.8-4,
3.8-5
LE.23 timer 2 start condition 0D17h rw np E 0 15 0 1 --- 3.8-3, 3.8-4
LE.24 timer 2 reset inp. sel. 0D18h rw np E 0 4095 0 1 --- 3.4-9, 3.8-3, 3.8-5
LE.25 timer 2 reset condition 0D19h rw np
E 0 31 16 1 --- 3.8-3, 3.8-6
LE.26 timer 2 mode 0D1Ah rw np --- 0 63 0 1 --- 3.2-10, 3.8-3, 3.8-4
further on next side
