KEB combivert R6-S Applications Manual

Parameter overview
© KEB, 2008-02 COMBIVERT R6-S Page 3.1 - 5
3
10
Parameter Addr. R P E Lower limit Upper limit Default Step Unity Reference
Pn.00 auto retry UP 0400h rw np --- 0:off 1:on 1:on 1 --- 3.6-9, 3.7-3
Pn.02 auto retry OC 0402h rw np --- 0:off 1:on 0:off 1 --- 3.6-9
Pn.03 E.EF stopping mode 0403h rw np --- 0 6 0 1 --- 3.6-6, 3.6-7, 3.6-8, 3.6-9
Pn.04 ext. fault input select 0404h rw np E 0 4095 64 1 --- 3.4-9, 3.6-5
Pn.05 E.bus stopping mode 0405h rw np --- 0 6 6 1 ---
3.6-3, 3.6-6, 3.6-7, 3.6-8,
3.6-9
Pn.06 watchdog time 0406h rw np E 0,00:off 60,00 0,00:off 0,01 s 3.6-6
Pn.08 warning OL stop mode 0408h rw np --- 0 6 6 1 --- 3.4-13, 3.6-5, 3.6-8, 3.6-9
Pn.09 OL warning level 0409h rw np --- 0 100 80 1 % 3.4-13, 3.6-5, 3.6-10
Pn.10 warning OH stop mode 040Ah rw np --- 0 6 6 1 ---
3.4-13, 3.6-3, 3.6-5, 3.6-8,
3.6-9
Pn.11 OH warning level 040Bh rw np --- 0 variable 70 1 Grad 3.4-13, 3.6-3, 3.6-5, 3.6-9
Pn.12 warning dOH stop. mode 040Ch rw np --- 0 7 7 1 --- 3.6-8, 3.6-9
Pn.14 disconnecting time E.nEt 040Eh rw np --- 0,00 10,00 0,00 0,01 s 3.6-8, 3.6-9, 5.1-3
Pn.15 automatic fault reset 040Fh rw np --- 0 10 3 1 --- 3.6-2, 3.6-9
Pn.16 warning OHI stop. mode 0410h rw np --- 0 6 0 1 --- 3.6-5, 3.6-8, 3.6-9, 3.6-9
Pn.17 E.OHI delay time 0411h rw np --- 0 300 0 1 s 3.6-5
Pn.18 E.Set stopping mode 0412h rw np --- 0 6 0 1 --- 3.6-6, 3.6-7, 3.6-8, 3.7-9
Pn.19 operating mode 0413h rw np E 0 3 0 1 ---
3.4-3, 3.5-3, 3.6-10, 4.2-3,
4.2-4, 4.2-5
ru.00 inverter state 0200h ro np --- 0 255 0 1 --- 3.2-5, 3.6-3
ru.03 actual frequency display 0203h ro np --- -320,00 320,00 0,00 0,01 Hz
3.2-5, 3.3-3, 3.3-4, 3.9-6,
4.2-4
ru.08 AC current L1 0208h ro np --- 0,0 6553,5 0,0 0,1 A 3.2-5
ru.09 AC current L2 0209h ro np --- 0,0 6553,5 0,0 0,1 A 3.2-5
ru.10 AC current L3 020Ah ro np --- 0,0 6553,5 0,0 0,1 A 3.2-5
ru.11 input voltage 020Bh ro np --- 0 1000 0 1 V 3.2-5
ru.13 actual utilization 020Dh ro np --- 0 255 0 1 % 3.2-6
ru.14 peak utilization 020Eh rw np --- 0 255 0 1 % 3.2-6
ru.15 DC current 020Fh ro np --- 0,0 6553,5 0 0,1 A 3.2-6, 3.3-3, 3.3-4
ru.16 DC current / peak value 0210h rw np --- 0,0 6553,5 0 0,1 A 3.2-6
ru.17 AC input current 0211h ro np --- -3276,7 3276,7 0 0,1 A 3.2-6, 3.3-3, 3.3-4
ru.18 DC voltage/ reference value 0212h ro np --- 0 1000 0 1 V
3.2-6, 3.3-3, 3.3-4, 3.5-4,
4.2-4
ru.19 DC output voltage 0213h ro np --- 0 1000 0 1 V 3.2-6, 3.2-7
ru.20 peak DC voltage 0214h rw np --- 0 778 0 1 V 3.2-7
ru.21 input terminal state 0215h ro np --- 0 4095 0 1 --- 3.2-7, 3.4-3, 3.4-5
ru.22 internal input state 0216h ro np --- 0 4095 0 1 ---
3.2-7, 3.2-18, 3.4-3, 3.4-5,
3.4-14
ru.23 output condition state 0217h ro np --- 0 255 0 1 --- 3.2-8, 3.4-11, 3.4-12
ru.24 stateofoutputags 0218h ro np --- 0 255 0 1 --- 3.2-8, 3.4-11, 3.4-12
ru.25 output terminal state 0219h ro np --- 0 255 0 1 ---
3.2-9, 3.2-18, 3.4-11,
3.4-12, 3.4-18, 7.1-4
ru.26 active parameter set 021Ah ro np --- 0 7 0 1 --- 3.2-9
ru.33 ANOUT1 pre ampl. disp. 0221h ro np --- -400,0 400,0 0 0,1 % 3.2-9, 3.3-4
ru.34 ANOUT1 post ampl. disp. 0222h ro np --- -100,0 100,0 0 0,1 % 3.2-9, 3.3-4, 3.4-14
ru.38 power module temperature 0226h ro np --- 0 100 0 1 Grad 3.2-9, 3.3-3, 3.3-4, 3.4-13
ru.39 OL counter display 0227h ro np --- 0 100 0 1 % 3.2-10, 3.4-13, 3.6-5
ru.40 power on counter 0228h rw np --- 0 65535 0 1 h 3.2-10, 3.7-3
ru.41 modulation on counter 0229h rw np --- 0 65535 0 1 h 3.2-10
ru.43 timer 1 display 022Bh rw np --- 0 655,35 0 0,01 --- 3.2-10, 3.4-13, 3.8-3, 3.8-5
ru.44 timer 2 display 022Ch rw np --- 0 655,35 0 0,01 --- 3.2-10, 3.4-13, 3.8-3, 3.8-5
ru.46 ext. temperature 022Eh ro np --- 0 255 0 1 --- 3.2-10
ru.68 rated DC voltage 0244h ro np --- 0 1000 0 1 V 3.2-10
ru.80 digital output state 0250h ro np --- 0 255 0 1 ---
3.2-11, 3.2-17, 3.4-11,
3.4-12, 3.4-18
ru.81 active power 0251h ro np --- -3200,00 3200,00 0,00 0,01 kW
3.2-11, 3.3-3, 3.3-4, 3.4-14,
4.2-4, 4.2-5
ru.82 total regen 0252h rw np --- 0 2147483647 0 1 kWh 3.2-11
ru.83 total motor 0253h rw np --- 0 2147483647 0 1 kWh 3.2-11
ru.84 total net 0254h rw np --- 0 2147483647 0 1 kWh 3.2-11
ru.85 actual net 0255h ro np --- 0,00 655,35 0 0,01 kVA 3.2-11
SY.02 inverteridentier 0002h cp-ro np --- identier identier identier 1 hex 3.2-16, 3.7-3
SY.03 power unit code 0003h cp-ro np E 0 32767 0 1 --- 3.2-16, 3.6-7, 5.1-5
SY.06 inverter address 0006h rw np E 0 239 1 1 --- 3.2-16, 7.1-4
SY.07 baud Rate ext. bus / PC 0007h rw np E 0 6 3 1 --- 3.2-16
SY.09 HSP5 watchdog time 0009h cp-ro np E 0,00:off 10,00 0,00:off 0,01 s 3.2-16, 3.6-6
SY.11 baud rate int. bus 000Bh cp-ro np E 0 10 5 1 --- 3.2-17
SY.32 scope timer 0020h ro np --- 0 65535 0 1 --- 3.2-17
SY.41 control word (high) 0029h rw np E 0 65535 0 1 hex 3.2-17, 3.2-18
SY.42 status word (high) 002Ah ro np --- 0 65535 0 1 hex 3.2-17, 3.2-18, 3.2-19
further on next side
