KEB combivert R6-S Applications Manual

Page 3.2 - 16 COMBIVERT R6-S © KEB, 2008-02
Operating and appliance data
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.11 Baud rate int. bus 000Bh rw - + 3 10 1 - 5
The transmission speed between operator/inverter or PC/inverter is determined with the internal baud rate.
Followingvaluesarepossible:
Value Baud rate Value Baud rate Value Baud rate
3 9,6 kBaud 6 55,5 kBaud 9 115,2 kBaud
4 19,2 kBaud 7 57,6 kBaud 10 125 kBaud
5 38,4 kBaud 8 100 kBaud 11 250 kBaud
After Power-On it is always started with 38.4 kBaud and dependent on the operator higher set.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.32 Scope timer 0020h ro - - 0 65535 1 - 0
The scope timer generates a time period of 1 ms. This can be used by external programs, e.g. scope, to
represent timepatterns.Thetimercountsfrom0...65535andstartsagainwith0afteranoverow.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.41 Control word high 0029h rw - + 0 65535 1 - 0
The control word is used for status control of the inverter via bus. The control word long (SY.43) consists of
the two 16 bit parameters control word high (SY.41) and control word low (SY.50). The status word is bit-
coded.
Bit Function Value Description
16 I1 1:I1
Corresponding input is set via the control word instead via hardware input.
These bits are only effective if the bit for the appropriate input is set in di.01
„select signal source“. Then the OR operation of this bit with the correspon-
ding bits of parameter di.02 " digital input setting" is valid.
17 I2 2:I2
18 I3 4:I3
19 I4 8:I4
20 IA 16:IA
21 IB 32:IB
22 IC 64:IC
23 Id 128:Id
24 O1 256:O1 Appropriate output is set via the control word or via the switching conditions.
Output signals O1, O2, R1 and R2 (visible in parameter ru.80) are OR ope-
rated with the appropriate bits of the control word. The connection occurs
according di.42 „inverted outputs “(inverting level for the output signals) and
before they are switched to the hardware outputs with do.51 „ hardware
output allocation“.
25 O2 512:O2
26 R1 1024:R1
27 R2 2048:R2
28...31 reserved
