Operating and appliance data
© KEB, 2008-02 COMBIVERT R6-S Page 3.2 - 17
3
10
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.42 Status word high 002Ah ro - - 0 65535 1 - 0
The current condition of the COMBIVERT can be readout with the status word. The status word long
(SY.44) consists of the two 16 bit parameters status word high (SY.42) and status word low (SY.51). The
status word is bit-coded.
Bit Value Description
0..7
1:I1
Display of the internal input terminal status (input terminals and software inputs after
the input processing block). Corresponds to the display in ru.22 „internal input state“
2:I2
4:I3
8:I4
16:IA
32:IB
64:IC
128:Id
8..15
256:O1
Display of the state of the output terminals and the software outputs (digital outputs
after the output processing block). Corresponds to the display in ru.25 „output termi-
nal state“
512:O2
1024:R1
2048:R2
4096:OA
8192:OB
16384:OC
32768:OD
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.43 Control word long 002Bh KB - + -2147483648 2147483647 1 - 0
The control word is used for status control of the inverter via bus. The control word long (SY.43) consists of
the two 16 bit parameters control word high (SY.41) and control word low (SY.50). The status word is bit-
coded.
Parameter Addr. R PG E Min. value Max. value Res. [?] Default
SY.44 Status word long 002Ch ro - - -2147483648 2147483647 1 - 0
The current condition of the COMBIVERT can be readout with the status word. The status word long
(SY.44) consists of the two 16 bit parameters status word high (SY.42) and status word low (SY.51). The
status word is bit-coded.
