Operation Manual Supply Unit SO CM-P BG1+2
ID no.: 1400.201B.5-00 Date: 02/2020
Climatic conditions ServoOne CM-P supply unit
In storage
As per EN61800-2, IEC60721-3-1 classes 1K3 and 1K4
2)
Temperature -25°C to +55°C
Relative atmospheric humidity 5 to 95%
In operation
As per EN61800-2, IEC60721-3-3 class 3K3
3)
Temperature Air cooling 5°C to +40°C
Relative atmospheric humidity 5 to 85% without condensation
1) The absolute humidity is limited to max. 60g/m³. This means, at 70°C for example, that the relative atmospheric humidity
may only be max. 40%.
2) The absolute humidity is limited to max. 29g/m³. So the maximum values for temperature and relative atmospheric humidity
stipulated in the table must not occur simultaneously.
3) The absolute humidity is limited to max. 25g/m³. That means that the maximum values for temperature and relative atmos-
pheric humidity stipulated in the table must not occur simultaneously.
Table A.6 Climatic conditions, supply unit ServoOne CM-P
NOTE:
The climatic conditions apply to the device. For this reason they must also be
met in the switch cabinet.
Mechanical conditions ServoOne CM-P supply unit
Vibration limit in transit
As per EN61800-2, IEC60721-3-2 class 2M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2<f<9 3.5 Not applicable
9<f<200 Not applicable 10
200<f<500 Not applicable 15
Shock limit in transit
As per EN61800-2, IEC60721-3-2 class 2M1
Drop height of packed device max. 0.25m
1) Note: The devices are only designed for stationary use.
Table A.7 Mechanical conditions, ServoOne CM-P
Mechanical conditions ServoOne CM-P supply unit
Vibration limits for the
system
1)
As per EN61800-2, IEC60721-3-3 class 3M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2<f<9 0.3 Not applicable
9<f<200 Not applicable 1
1) Note: The devices are only designed for stationary use.
Table A.7 Mechanical conditions, ServoOne CM-P
CAUTION! DAMAGE TO THE DEVICE DUE TO INCORRECT OPERATION!
Failure to observe the ambient conditions may result in damage.
x No continuous vibration!
The axis controllers must not be installed in areas where they would be permanently
exposed to vibration.
x Switch cabinet min. IP54 for STO! as per ENISO13849-2
x Observe cooling conditions!
NOTE:
The devices are only designed for stationary use.
