A.7.1 Overview of mains lters
Mains input current I
IN
≤ 25 A
Max. motor cable length [m] 20 30 40 50 60 70 80 90 100 120 140 240 300 600
Category
C2
Clock frequency [kHz]
4 EMC25.120-UR EMC25.240-UR EMC25.600-UR N/A
8 EMC25.120-UR EMC25.240-UR EMC25.600-UR N/A
16 EMC25.240-UR N/A
C3
4 EMC25.120-UR EMC25.240-UR EMC25.600-UR
8 EMC25.120-UR EMC25.240-UR
EMC25.600-UR
16 EMC25.120-UR N/A
KEBA article designation KEBA article no.
EMC25.120-UR 0996.2027
EMC25.240-UR 0996.2026
EMC25.600-UR 0996.2025
Table A.9 Selection, mains lter for SOCM-P.0010 / SOCM-P.0110
Mains input current I
IN
≤ 53 A
Max. motor cable length [m] 20 30 40 50 60 70 80 90 100 120 140 240 300 600
Category
C2
Clock frequency [kHz]
4 EMC53.120-UR EMC53.240-UR EMC53.600-UR N/A
8 EMC53.240-UR EMC53.600-UR N/A
16 EMC53.240-UR EMC53.600-UR N/A
C3
4 EMC53.120-UR EMC53.240-UR EMC53.600-UR
8 EMC53.120-UR EMC53.240-UR EMC53.600-UR
16 EMC53.120-UR EMC53.240-UR N/A
KEBA article designation KEBA article no.
EMC53.120-UR 0996.2024
EMC53.240-UR 0996.2023
EMC53.600-UR 0996.2022
Table A.10 Selection, mains lter for SOCM-P.0022 / SOCM-P.0122
