1.5 TORQUE VALUES
FRAME
● Handlebar upper holder bolt
24 N.m (17.7 lbf.ft)
● Throttle housing cover screw
4 N.m (2.9 lbf.ft)
● Steering shaft nut
50 N.m (36.9
lbf.ft)
● Steering shaft holder bolt
33 N.m (24 lbf.ft)
● Wheel rim bolt
18 N.m (13.3 lbf.ft)
● Tie rod lock nut
35 N.m (25.8 lbf.ft)
● King pin nut
40 N.m (29 lbf.ft)
● Handlebar lower holder nut
40 N.m (29.5 lbf.ft)
● Front wheel bolt
24 N.m
(17.7 lbf.ft)
● Front axle castle nut
40
-
60 N.m (30
-
45 lbf.ft)
● Front brake arm nut
4 N.m (3.0 lbf.ft)
● Rear brake arm nut
7 N.m (5.2 lbf.ft)
● Rear axle castle nut
40
-
60 N.m (30
-
45 lbf.ft)
● Rear wheel bolt
24 N.m (17.7 lbf.ft)
● Exhaust muffler mounting bolt
30 N.m (22.1 lbf.ft)
● Engine hanger bolt
30 N.m ( 22 lbf.ft)
● Rear axle holder bolt
90 N.m (65 lbf.ft)
● Swing arm pivot nut
90 N.m (65 lbf.ft)
● Rear shock absorber mounting nut
45 N.m (33 lbf.ft)
STANDARD
● 5 mm bolt and nut
5 N.m (3.5 lbf.ft)
● 6 mm bolt and nut
10 N.m (7.2 lbf.ft)
● 8 mm bolt and nut
22 N.m (16 lbf.ft)
● 10 mm bolt and nut
35 N.m (25 lbf.ft)
● 12 mm bolt and nut
55 N.m (40 lbf.ft)
ENGINE
● Cylinder head nut
28 N.m (20.7 lbf.ft)
● Spark plug
12 N.m (8.9 lbf.ft)
● Cylinder head bolt
20 N.m (14.8 lbf.ft)
● Alternator bolt
8 N.m (5.9 lbf.ft)
