KEEWAY ATV300 - Electrical System; Electrical System Troubleshooting

97
14. ELECTRICAL SYSTEM
1
4
.1 TROUBLESHOOTING
14.2 IGNITION COIL
14.3 IGNITION TIMING
14.4 BATTERY INFORMATION
1
4
.5 ELECTRIC STARTER
14.6 LIGHT BULBS REPLACEMENT
14.7 INSTRUMENT PANEL
14.8 WIRING DIAGRAM
14.9Electrical starter switch
14.1 TROUBLESHOOTING
ENGINE STARTS BUT STOPS ★ IMPROPER IGNITION TIMING
★ FAULTY SPARK PLUG
NO SPARK AT PLUG ★ ENGINE STOP SWITCH AT “ OFF “ POSTION
★ GEARSHIFT BAR IS NOT AT NORMAL POSITION
★ FAULTY IGNITION COIL
★ FAULTY GENERATOR
★ FAULTY CDI UNIT
★ POOLY CONNECTED:
Between CDI and ignition coil
Between alternator and CDI unit
Between CDI and engine stop switch
Between ignition coil and spark plug
Between generator and CDI unit
ENGINE STARTS BUT RUNS POORLY ★ IGNITION PRIMARY CIRCUIT
Faulty generator
Faulty CDI unit
Faulty alternator exciter coil
Loosen contacted terminals
Faulty ignition coil
★ IGNITION SECONDARY CIRCUIT
Faulty plug
Loosen contacted spark plug wire
★ IMPROPER IGNITION TIMING
Faulty generator
Faulty CDI unit
CHARGING SYSTEM FAILURE ★ LOOSE, BROKEN OR SHORTED WIRE
★ FAULTY ALTERNATOR
★ FAULTY IGNITION SWITCH
ENGINE INTERMITTENT POWER ★ LOOSE BATTERY CONNECTION
★ LOOSE CHARGING SYSTEM CONNECTION
STARTER MOTOR CAN NOT WORK ★ BATTERY SHORTAGE
★ FAULTY IGNITION SWITCH
★ LOOSE OR DISCONNECTED WIRE
ENGINE CAN NOT WORK ★ FAULTY IGNITION SYSTEM
★ ENGINE PROBLEMS
★ FAULTY ENGINE STOP SWITCH
HEAD LIGHT CAN NOT WORK ★ THE SWITCH DO NOT TURN TO “ON” POSITION
★ THE LIGHT BULB WAS BROKEN, REPLACED
