11.4 THROTTLE HOUSING
DISASSEMBLY
·
··
·
Loosen the screws on the throttle housing cover.
·
··
·
Remove throttle housing cover and gasket.
·
··
·
Disconnect throttle cable from the throttle arm
and remove from the throttle housing.
NOTE:
Assembly is in the reverse order of disassembly
11.5 STEERING SYSTEM
Removal of Kingpin and Tie-rod
Remove the front wheels and hub assy.
Remove the four self-lock nuts from the tie-rod ball
joints and take off the two tie-rods
Tie-rod Inspection
Inspect the tie-rod for damage or bending.
Inspect the ball joint rubbers for damage,
wear or deterioration.
Turn the ball joints with fingers. The ball joints
should turn smoothly and quietly
