KEEWAY ATV300 - Front Wheel and Brake Troubleshooting; Front Wheel Service

91
12.2 TROUBLESHOOTING
HARD STEERING ★ Faulty tire
★ Insufficient tire pressure
FRONT WHEEL WOBBLING ★ Faulty tire
★ Worn front brake drum bearing
★ Bent rim
★ Axle nut not tightened properly
BRAKE DRAG ★
★★
★ Incorrect brake adjustment
★ Sticking brake cable
STEERS TO ONE SIDE ★ Bent tie rods
★ Wheel installed incorrectly
★ Unequal tire pressure
★ Incorrect wheel alignment
POOR BRAKE PERFORMANCE ★ Brake shoes worn
★ Worn brake drum
★ Brake linings oily, greasy or dirty
★ Improper brake adjustment
12 .3 FRONT WHEELS
REMOVAL
(The disassemble of front wheel system
in this serials are the same)
Raise the front wheels off the ground by placing a jack
or other support under the frame.
Remove the front wheel nuts, washer and wheels
INSTALLATION
Install and tighten the four-wheel nuts
Torque: 24 N.m (17.7 lbf.ft)
Remember put a cotter pin in the castle nut
