Keithley 2302 User Manual

12-16 SCPI Tables
Table 12-5
SOURce command summary (refer to Table 2-3)
Command Description
Default
parameter
SCPI
[:SOURce[1]] SOURce subsystem for channel #1 (battery channel).
:VOLTage Path to set output voltage. ✓
:PROTection <NRf> Sets VPT offset (0–8V). 8V
:PROTection? Query setting for VPT offset.
:STATe? Query state of VPT — no associated
command.
:CLAMp <b> Sets VPT clamp mode ON or OFF. OFF
:CLAMp? Query state of VPT clamp mode.
[:LEVel] ✓
[:IMMediate]
[:AMPLitude]
<n>
Specify voltage amplitude in volts: 0–15V
w
ith 1mV resolution.
0.0 ✓
[:AMPLitude]? Query voltage amplitude. ✓
:CURRent Path to configure current. ✓
[:LIMit] Path to configure current limit.
[:VALue] <NRf> Specify current limit value in amps: 0.006–5
w
ith 100μA resolution.
0.25
[:VALue]? Query current limit.
:TYPE <name> Select current limit type: LIMit or TRIP. LIM
:TYPE? Query current limit type.
:STATe? Query state of current limit: 1 = in current
lim
it (for LIMit type) or output tripped (for
TRIP type), 0 = not in LIMit/TRIP.
:SOURce2 SOURce subsystem for channel #2 (charger channel).
:VOLTage Path to set output voltage. ✓
:PROTection <NRf> Sets VPT offset (0–8V). 8V
:PROTection? Query setting for VPT offset.
:STATe? Query state of VPT—no associated command.
:CLAMp <b> Sets VPT clamp mode ON or OFF.
OFF
:CLAMp? Query state of VPT clamp mode.
[:LEVel] ✓
[:IMMediate]
[:AMPLitude]
<n>
Specify voltage amplitude in volts: 0–15
with 1mV
resolution.
0.0 ✓
[:AMPLitude]? Query voltage amplitude. ✓
:CURRent Path to configure current. ✓
