13-10 Performance Verification
2. Select the multimeter DC voltage measuring function, and enable auto-ranging.
3. Select Channel #1 by pressing the
â–²
and
â–²
keys to toggle between Channel #1 and
Channel #2. Turn on the Model 2306 output.
4. Verify compliance current accuracy for the currents listed in Table 13-4. For each test
point:
• Set the Model 2306 output voltage to 8V, and set the compliance current to the value
being tested.
• Note and record the digital multimeter
voltage reading.
• Calculate the current from the voltage reading and actual 1Ω
resistor value: I = V/R.
• Verify that the current is within the limits given in the table.
1. Repeat steps 1 through 4 for Channel #2 (use the
â–²
and
â–²
keys to toggle between
Channel #1 and Channel #2).
Table 13-4
Compliance current accuracy limits
Model 2306 compliance
current setting
Compliance current limits
(2 Years, 18°C-28°C)
1.000A 0.993 to 1.007A
2.000A 1.992 to 2.008A
3.000A 2.990 to 3.010A
4.000A 3.989 to 4.011A
4.500A 4.488 to 4.512A
