Replaceable Parts 16-3
Table 16-1
Model 2306 digital board parts list
Circuit designation Description Keithley part no.
C101,C141,C201 CAP, 10UF, 20%, 25V, TANTALUM C-440-10
C102,132,133,184,186,189,197-199,202,300 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C105,106,107,130,205,206,207,230 CAP, 100U, 20%, 20V, ALUM ELEC C-583-100
C108,114,115,127,129,135,136,137,151,158 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C111,C119,C152,C211,C219,C252 CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C112,C113,C212,C213 CAP, 10U, 20%, 35V, TANTALUM C-551-10
C120,123,131,142,156,193,196,220,223 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C121,C122,C221,C222 CAPACITOR C-570-470
C124,126,128,153,192,194,224,226,228 CAP, 22UF, 20%, 25V, TANTALUM C-440-22
C125,C150,C225,C301 CAP, 22U, 20%, 25V, TANTALUM C-535-22
C134,144,159,160,161,163,164,165,166,167 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C138,C139 CAP, .47U, 20%, 25V C-520-.47
C140 CAP, 2.2U, 10%, 50V, TANTALUM C-563-2.2
C143,C311 CAP, 0.022UF, 10%, 50V, CERAMIC C-491-.022
C145,309 CAP, 270PF, 5%, 100V, CERAMIC C-465-270P
C146,C308 CAP, 1000PF, 10%, 50V, MONO CERAMIC C-452-1000P
C147,C310 CAP, 100PF, 5%, 100V, CERAMIC C-465-100P
C148 CAP, 0.01uF, 20%, 50V, CERAMIC C-418-.01
C149 CAP, 0.47U, 20%, 25V C-520-.47
C154 CAP, 220UF, ±20%, 50V, ALUM ELEC C-507-220
C155 CAP, 0.01uF, 20%, 50V, CERAMIC C-418-.01
C157 CAP, 100UF, 20%, 16V, TANTALUM C-504-100
C162,C262 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
C168,169,173,175,176,177,178,179,180,181 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C170,C174 CAP, 0.01UF, 10%, 50V, CERAMIC C-491-.01
C171,C172 CAP, 15P, 1%, 100V, CERAMIC C-512-15P
C182,188,195,208,214,215,227,229,258,268 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C183 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C190,191,234,259,260,261,263,264,265 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C231,307 CAP, 0.1UF, 20%, 50V, CERAMIC C-418-.1
C266,267,306 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C269,C302,C369 CAP, 0.1UF, 10%, 25V, CERAMIC C-495-.1
C303,C304,C305,C100,C200 CAP, 47P, 5%, 100V, CERAMIC C-465-47P
CR100,CR200 DIODE, DUAL HSM-2822T31 RF-95
CR101,CR201 RECTIFIER RF-135
