Keithley 2302 User Manual

16-4 Replaceable Parts
CR102,CR202 ULTRA FAST BRIDGE RECTIFIER,
EDF1BM
RF-123
CR104,CR106,CR204,CR206 DIODE, MBRS140T3 RF-110
CR107,CR207 RECTIFIER RF-134
CR108 DIODE MBR5130LT3 RF-115
CR109,CR110,CR209,CR210 DIODE, SWITCHING, MMSD914T19 RF-112
CR111,CR112,CR211,CR212 DIODE, DUAL SWITCHING, BAV99L RF-82
FH100,101,200,201 FUSE HOLDER, LITTLEFUSE 111501 FH-33
J1002 CONN, MOLEX, 3-PIN CS-772-3
J1003 CONN, RIGHT ANGLE, 24 PIN CS-501
J1004 SHIELDED RT. ANGLE PHONE JACK CS-981
J1007,J1010 CONN MALE 5-PIN CS-1060-5
J1008 CONN, HEADER, STRAIGHT SOLDER
PIN
CS-368-10
J1009 CONN, HEADER, STRAIGHT SOLDER
PIN
CS-368-34
L100,101,104,116,200,201 LINE FILTER CH-85-10
L102 CHOKE CH-56-1
L103 POWER INDUCTOR CH-97-1
L105 CHOKE 1.2A CH-94-1
L106,L107,L109,L110,L111,L112 FERRITE CHIP 600 OHM BLM32A07 CH-62
L108,L115 FERRITE BEAD CH-91
PS100 POWER SUPPLY PS-72A
Q100,101,200,201 TRANSISTOR SMT TG-371
R101,R105,R201,R205 RES, 200, 5%, 250MW, METAL FILM R-376-200
R112 RES, 10, 10%, 100MW, THICK FILM R-418-10
R113,R114,R136,R159,R236 RES, 100, 1%, 100MW, THICK FILM R-418-100
R115,149,166,168,100,118,179,181,184,200 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R116,R178 RES, 10M, 1%, 125MW
, THICK FILM R-418-10M
R117,R180 RES, 1M, 1%, 100MW
, THICK FILM R-418-1M
R118,121,134,145,146,147,148,150,152,157 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R119 RES, 66.5K, 1%, 100MW, THICK FILM R-418-66.5K
R120 RES, 1M, 1%, 100MW
, THICK FILM R-418-1M
R122 RES, 24.9K, 1%, 100MW, THICK FILM R-418-24.9K
R123 RES, 20K, 1%, 100MW, THICK FILM R-418-20K
R124 RES, 2.55K, 1%, 1W, THICK FILM R-418-2.55K
R125 RES, 11K, 1%, 100MW, THICK FILM R-418-11K
Table 16-1
Model 2306 digital board parts list (cont.)
Circuit designation Description Keithley part no.
