Keithley 2302 User Manual

Replaceable Parts 16-9
CR414,415,614,615 DIODE, MBRS140T3 RF-110
J1007,J1010 CONN, MALE 5-PIN CS-1060-5
J1009 CONN, HEADER, STRAIGHT SOLDER
PIN
CS-368-34
J1014,J1015 CONNECTOR, MODULES CS-834
L400,L401,L402,405-408,600-602,605-608 FERRITE CHIP 600 OHM BLM32A07 CH-62
L403,L404,L603,L604 FERRITE CHIP 600 OHM BLM32A07 CH-62
L409,L609,L413,L613 CHOKE SMT CH-66-100
L410,L411,L610,L611 CHOKE CH-98-1
L412,L612 CHOKE, 22UH CH-66-22
Q400-403,600-603 TRANS, N-MOSFET, VN0605T TG-243
Q404,Q604 TRANS, NPN, MMBT3904 TG-238
Q405,Q605 TRANS, PNP, MMBT3906L TG-244
Q406,Q606 TRANSISTOR SMT TG-371
Q407,Q408,Q607,Q608 HEXFET POWER MOSFET TG-354
Q409-416,431-438,610-616,609,417,630 TRANS, N CHANNEL JFET, SNJ132199 TG-294
Q418,Q419,Q422,Q618,Q619,Q622 TRANS, N CHANNEL FET, 2N4392 TG-128-1
Q421,Q621 TRANS, CURRENT REGULATOR TG-341
Q423,Q623 PNP SILICON TRANSISTOR TG-310
Q424,Q429,Q620,Q624 N CHANNEL POWER MOSFET TG-349
Q425,Q430,Q625,Q629 P CHANNEL POWER MOSFET TG-348
Q426,626 NPN SILICON TRANSISTOR TG-309
Q427,Q428,Q627,Q628 TRANSISTOR SMT TG-376
R400,R600 RES NET TF-245
R401,R601 RES, 6.04K, 1%, 125MW, THIN FILM R-423-6.04K
R402,R404,R602,R604 RES, 2.21K, 1%, 100MW, THICK FILM R-418-2.21K
R403,R603 RES, 1.28M, 0.1%, 1/8W, METAL FILM R-176-1.28M
R405,R414,R587,R588,R751,R752,R44
3,
R532
RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R406,R421,R606,R621 RES, 100, 1%, 100MW, THICK FILM R-418-100
R407,463,466,468,661,662,685,686,687,697 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R408,R608 RES, 5.11K, 1%, 100MW, THICK FILM R-418-5.11K
R409,R609,R454,R456 RES, 470, 5%, 125MW, METAL FILM R-375-470
R410,R412,R569,R61
0,R612,R660,R723 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R411,R611,R504,R508 RES, 10, 10%, 100MW, THICK FILM R-418-10
R413,R531,R613,R731 RES, 6.04K, 1%, 100MW, THICK FILM R-418-6.04K
R415,R615 RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
Table 16-2
Model 2306 analog board parts list (cont.)
Circuit designation Description Keithley part no.
