Keithley 2302 User Manual

16-10 Replaceable Parts
R416,R616,R721,R724 RES, 475, 1%, 100MW, THICK FILM R-418-475
R417,556,593,651,758 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R418,R618 RES, 34K, 1%, 100MW, THICK FILM R-418-34K
R419,R619 RES, 82.5, 1%, 100MW
, THICK FILM R-418-82.5
R420,R620 RES, 4.75K, 1%, 100MW, THICK FILM R-418-4.75K
R422,R447,R622,R674,R496,R647 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R423,R623 RES, 3.01K, 1%, 125MW, METAL FILM R-391-3.01K
R424,R425,R570,R624,R625,R650 RES, 10K, 5%, 250MW, METAL FILM R-376-10K
R426,427,449,626,627 THICK FILM TF-273-1
R429,R629 RES, 0.1, 1%, 3W R-475-.1
R430,444,460,461,467,469,470,455,485,486 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R431,R631 RES, 100, 0.1%, 1/2W, METAL FILM R-169-100
R432,R550,R450 RES, 10K, 5%, 250MW, METAL FILM R-376-10K
R435,R438,R635,R638 RES, 4.7K, 5%, 250MW, METAL FILM R-376-4.7K
R436,R636 RES, 470K, 5%, 250MW, METAL FILM R-376-470K
R437,R597,R637,R671 RES, 1M, 0.1%, 0.125MW, THIN FILM R-456-1M
R439,R639,R665 THICK FILM TF-273-4
R440,441,640,641 THICK FILM TF-273-2
R442,R642 RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R445,R645 RES, 15K, 1%, 100MW, THICK FILM R-418-15K
R446,646 RES, 909, 1%, 1W, THICK FILM R-418-909
R448,R648 RES, 249K, 1%, 100MW, THICK FILM R-418-249K
R451,R527 RES, 2.55K, 1%, 1W, THICK FILM R-418-2.55K
R452,R453,R458 RES, 2.55K, 1%, 1W, THICK FILM R-418-2.55K
R454,R579,R655,R744 RES, 6.04K, 1%, 100MW, THICK FILM R-418-6.04K
R457,R515 RES, 2.74K, 1%, 0.1W, THICK FILM R-418-2.74K
R464,R472,R632,R750 RES, 1K, 5%, 250MW, METAL FILM R-376-1K
R465,R473,R522,R523 RES, 1M, 1%, 100MW
, THICK FILM R-418-1M
R474,R477,R511,R67
7,R696,R495,R652 RES, 100K, 1%, 100MW, THICK FILM R-418-100K
R475,478,534,668,675,678,690,734,594,669 RES, 4.99K, 1%, 100MW, THICK FILM R-418-4.99K
R476,R676,R595,R667 RES, 1M, 1%, 100MW
, THICK FILM R-418-1M
R481 RES, 9.76K, 1%, 100MW, THICK FILM R-418-9.76K
R483,683,688,689,692,693,694,699,700 RES, 10K, 0.1%, 0.125W, THIN FILM R-456-10K
R484,R516,R518 RES, 20K, 1%, 100MW, THICK FILM R-418-20K
R488,R489,R492,R49
3,R494,R499,R500 RES, 10K, 0.1%, 0.125W, THIN FILM R-456-10K
R491 RES, 4.99K, 1%, 100MW, THIN FILM R-438-4.99K
Table 16-2
Model 2306 analog board parts list (cont.)
Circuit designation Description Keithley part no.
