Replaceable Parts 16-11
R497,R498,R644,R549,R749 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R501,R510,R701,R710 RES, 100, 1%, 100MW, THICK FILM R-418-100
R502,R596,R659,R664 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R503,R509,R575,R576 RES, 499, 1%, 100MW, THICK FILM R-418-499
R505,R506,R507,R586,R705,R706 RES, 0.2, 1%, 30W R-463-.2
R514,R583 RES, 2.49K, 0.1%, 0.125MW, THIN FILM R-456-2.49K
R517,R519,R551,R630 RES, 24.9K, 1%, 100MW, THICK FILM R-418-24.9K
R526 RES, 80.6K, 1%, 100MW, THICK FILM R-418-80.6K
R528,R535 RES, 9.76K, 1%, 100MW, THICK FILM R-418-9.76K
R529,R729 RES, 3.32K, 1%, 100MW, THICK FILM R-418-3.32K
R530,730 RES, 237, 1%, 100MW, THICK FILM R-418-237
R533,R524,R617 RES, 10M, 1%, 125MW
, THICK FILM R-418-10M
R536,R653,R459,R513 RES, 0.0499, 1%, 100MW, THICK FILM R-418-.0499
R537,R737 RES, 16.9K, 1%, 0.1W, THICK FILM R-418-16.9K
R538,R738 RES, 59K, 1%, 100MW, THICK FILM R-418-59K
R539,R739 RES, 40.2K, 1%, 100MW, THICK FILM R-418-40.2K
R540,R740 RES, 40.2K, 1%, 100MW, THICK FILM R-418-40.2K
R542,R742 RES, 6.19K, 1%, 100MW, THICK FILM R-418-6.19K
R548,R748 RES, 0.015, 1.5W, 1% R-468-.015
R552 RES, 274, 1%, 0.1W, THIN FILM R-438-274
R553 RES, 2.49K, 1%, 0.1W, THIN FILM R-438-2.49K
R554 RES, 24.9K, 1%, 100MW, THIN FILM R-438-24.9K
R555 RES, 392, 1%, 100MW, THICK FILM R-418-392
R557,R543,R580,R657,R743 RES, 2K, 1%, 100MW, THICK FILM R-418-2K
R559,R564 RES, 475, 1%, 100MW, THICK FILM R-418-475
R565,568,566,605,614,663,716-720,722 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R571,R572 RES, 10K, 5%, 125MW, METAL FILM R-375-10K
R573 RES, 200, 1%, 100MW, THICK FILM R-418-200
R574 RES, 1.87K, 1%, 0.1W, THICK FILM R-418-1.87K
R578,R656 RES, 4.02K, 1%, 100MW, THICK FILM R-418-4.02K
R581,R658 RES, 8.06K, 1%, 0.1W, THICK FILM R-418-8.06K
R582,R670 RES, 1.5K, 1%, 100MW, THICK FILM R-418-1.5K
R584,R585 RES, 4.99K, 0.1%, 0.125W
, THIN FILM R-456-4.99K
R590,R756 RES, 11K, 1%, 100MW, THICK FILM R-418-11K
R591,R755 RES, 73.2K, 1%, 100MW, THICK FILM R-418-73.2K
R666,R592,R757 RES, 0.0499, 1%, 100MW, THICK FILM R-418-.0499
Table 16-2
Model 2306 analog board parts list (cont.)
Circuit designation Description Keithley part no.
