16-12 Replaceable Parts
R691 RES, 4.99K, 1%, 100MW, THIN FILM R-438-4.99K
R698,R741,R487,R54
1,R607,R490,R649 RES, 1K, 1%, 100MW, THICK FILM R-418-1K
R703,R709 RES, 499, 1%, 100MW, THICK FILM R-418-499
R707 RES, 0.1, 1%, 30W R-463-.1
R711,R520,R521 RES, 49.9K, 1%, 100MW, THICK FILM R-418-49.9K
R725,726,563,482,525,561,567,643,712 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R732,628,558,560,562,577,428,462,471,512 RES, 10K, 1%, 100MW, THICK FILM R-418-10K
R733 RES, 10M, 1%, 125MW
, THICK FILM R-418-10M
R753,R754,R598,R672 RES, 10, 10%, 100MW, THICK FILM R-418-10
RT400,RT401 THERMISTER, PD=7MW/DEG C, 1500V,
613.74K
RT-8
RV400,RV600 TRANSIENT VOLTAGE SUPPRESSOR VR-19
RV401,RV601 VA R I S T O R VR-21
TP401,TP402-TP405,TP601-TP604,TP400 SURFACE MOUNT PCB TEST POINT CS-1026
TP600 CONNECTOR CS-985
U400,U600 PROGRAM 2000-802A02
U401,U601 IC, QUAD D FLIP FLOP W/CLK, RESET
74HC175
IC-923
U402,U403,U602,U603 IC, QUAD 2 IN NOR, 74HCT02 IC-809
U404,U604 IC, NCHAN LAT DMOS QUADFET,
SD5400CY
IC-893
U405,U605,U455,U466,U643,U654 INTEGRATED CIRCUIT, OPA177GS IC-960
U406,424,436,439,464,606,623,636,639 PRECISION BIFET OPAMP IC-1194
U407,U607 IC, DUAL BIPOLAR OP-AMP, LT1124CS8 IC-955
U409,U609 IC, OP-AMP, NE5534D IC-802
U410,435,448,461,610,648,652,653,444,625 IC, VOLT. COMPARATOR, LM311M IC-776
U411,U465 IC, OPAMP, LTC1150CS8 IC-1053
U412,U612 INTEGRATED CIRCUIT IC-1333
U413,U457,U613 LOW POWER INSTRUMENT AMP IC-1124
U414,415,421,423,438,614,615,638,425,449 IC, 20V OP-AMP, LT1097S8 IC-767
U416,U616 IC, 8-CHAN ANA MULTIPLEXER,
DG40
8DY
IC-844
U417,U452,U462,U617 IC, 8 STAGE SHIFT/STORE, MC14094BD IC-772
U418,U618 CMOS ANALOG SWITCH IC-1210
U419,U619 HIGH PRECISION 10V REFERENCE IC-1121
U420 INTEGRATED CIRCUIT IC-1281
U422 INTEGRATED CIRCUIT IC-1277
Table 16-2
Model 2306 analog board parts list (cont.)
Circuit designation Description Keithley part no.
