Keithley 2302 User Manual

16-18 Replaceable Parts
R104,R108,R204,R208 RES,7.5,5%,.5W THICK FILM R-469-7.5
R109,R110,R209,R210 RES,10,5%,250MW,METAL FILM R-376-10
R112 RES,10,10%,100MW,THICK FILM R-418-10
R113,R114,R136,R159,R236,R261,R26
2,
R264
RES,100,1%,100MW,THICK FILM R-418-100
R115,R149,R166,R100,R118,R179,R18
1,
R200
RES,10K,1%,100MW,THICK FILM R-418-10K
R116,R178 RES,10M,1%,125MW,THICK FILM R-418-10M
R117,R180 RES,1M,1%,100MW,THICK FILM R-418-1M
R119 RES,45.3K,1%,100MW THICK FILM R-418-45.3K
R120 RES,1M,1%,100MW,THICK FILM R-418-1M
R121,R134,R145,R146,R147,R148,R15
0,
R152
RES,10K,1%,100MW,THICK FILM R-418-10K
R122 RES,24.9K,1%,100MW,THICK FILM R-418-24.9K
R123 RES,20K,1%,100MW,THICK FILM R-418-20K
R124 RES,2.55K,1%,1W THICK FILM R-418-2.55K
R125 RES,11K,1%,100MW,THICK FILM R-418-11K
R126,R128,R130,R132,R137,R138,R13
9,
R140
RES,475,1%,100MW,THICK FILM R-418-475
R127,R129,R133,R227,R229,R233,R25
9,
R266
RES,475,1%,100MW,THICK FILM R-418-475
R131,R231 RES,1K,1%,1/4W METAL FILM R-391-1K
R135,R235 RES,1K,5%,250MW METAL FILM R-376-1K
R141,R142,R144,R226,R228,R230,R23
2,
R237
RES,475,1%,100MW,THICK FILM R-418-475
R143 RES,1K,1%,100MW,THICK FILM R-418-1K
R151,R165,R176 RES,4.75K,1%,100MW,THICK FILM R-418-4.75K
R153 RES,15K,1%,100MW,THICK FILM R-418-15K
R154 RES,332K,1%,100MW,THICK FILM R-418-332K
R155 RES,10M,1%,125MW,THICK FILM R-418-10M
R156 RES,499,1%,100MW,THICK FILM R-418-499
R157,R158,R161,R163,R164,R167,R17
5,
R234
RES,10K,1%,100MW,THICK FILM R-418-10K
R160 RES,866,1%,100MW THICK FILM R-418-866
R177,R174 RES,10K,1%,100MW,THICK FILM R-418-10K
R182,R183,R282,R283 RES,68,5%,125MW METAL FILM R-375-68
R238,R239,R240,R241,R242 RES,475,1%,100MW,THICK FILM R-418-475
Table 16-5
Model 2306-VS digital board parts list (cont.)
Circuit designation Description Keithley part no.
