Keithley 2302 User Manual

Replaceable Parts 16-19
R250,R252,R253,R255-R258,R260,R275,
R276
RES,.0499,1%,100MW,THICK FILM R-418-.0499
R263,R272 RES,1K,1%,100MW,THICK FILM R-418-1K
R265,R273 RES,4.75K,1%,100MW,THICK FILM R-418-4.75K
R267,R268 RES,475,1%,100MW,THICK FILM R-418-475
R269,R270,R271 RES,100,1%,100MW,THICK FILM R-418-100
R285 RES,.0499,1%,100MW,THICK FILM R-418-.0499
RT100 THERMISTOR,PD-7MW/DEG C,1500V,
613.74K
RT-8
RT101 INRUSH CURRENT LIMITER,ICL1516 RT-22
RV100 VARISTOR VR-23
S100 SWITCH,PUSHBUTTON (6 POLE) SW-466
SO125 SOCKET,PLCC-032-T-A SO-143-32
T100,T200 TRANSFORMER TR-338A
TE100-TE103 CONN,CONTACT PIN TE-110
TP100-TP-112,TP200-TP204 SURFACE MOUNT PCB TEST POINT CS-1026
U100,U200 I C,QUAD SCHMITT TRIG NAND GATE IC-1291
U101,U201 IC,DUAL D FLIP FLOP IC-1292
U102,U202 IC,TRIPLE 3 IN NAND,74F10 IC-659
U103,U203 IC,DUAL POWER MOSFET DRIVER,
ICL7667
IC-1118
U104,U204 IC,VOLTAGE REGULATOR IC-1132
U105,U205 IC,VOLTAGE REGULATOR IC-1133
U106,U206 IC,-15V VOLTAGE REGULATOR IC-1135
U107 IC,DUAL 4 BIT BIN COUNTER IC-1294
U108 IC,+5V RS-232 TRANSCEIVER,MAX202 IC-952
U109,U111 IC,VOLT COMPRATOR,LM393D IC-775
U110 IC,DUAL PICOAMP OP AMP,AD706JR IC-910
U112 IC,ADJ VOLTAGE REG STEP DOWN IC-1280
U113 IC,+5V VOLTAGE REGULATOR,
LM2940
CT
IC-576
U114,U122,U214,U138 IC,SCHMITT HEX INVERT IC-1293
U115,U116,U117,U119,U215,U216,U217,
U219
IC,HCPL0631,PACK IC-1153
U118,U120,U218,U220 IC,TINYLOGIC CMOS INVERTER IC-1282
U121 IC,GPIB ADAPTER,9914A (PLCC) LSI-123
U124 IC,512K X 8 BIT CMOS SRAM LSI-234-70
Table 16-5
Model 2306-VS digital board parts list (cont.)
Circuit designation Description Keithley part no.
