Table 16-6
Model 2306-VS display board parts list
Circuit designation Description Keithley part no.
C601,C602 CAP,33PF,10%,100V,CERAMIC C-451-33P
C603,C616 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C609 CAP,.1UF,10%,25V,CERAMIC C-495-.1
C611 CAP,10UF,20%,25V,TANTALUM C-440-10
C613 CAP,.1UF,20%,50V CERAMIC C-418-.1
C614,C615 CAP,390P,10%,100V,CERAMIC C-451-390P
J1008 CONN,HEADER STRAIGHT SOLDER PIN CS-368-10
J1013 CONNECTOR,RIGHT ANGLE CS-362
L601,L602,L603,L604 FERRITE CHIP 600 OHM BLM32A07 CH-62
R601 RES,10M,5%,125MW,METAL FILM R-375-10M
R602-R605,R611,R614,R616,
R61
8,R620,R623
RES,10K,1%,100MW,THICK FILM R-418-10K
R606,R608,R610,R613,R615,R617,
R61
9,R621
RES,15K,1%,100MW,THICK FILM R-418-15K
R607 RES,1.07K,1%,100W THIN FILM R-438-1.07K
R612 RES,4.75K,1%,100MW,THICK FILM R-418-4.75K
R622 RES,15K,1%,100MW,THICK FILM R-418-15K
RV601,RV602 300W TRANSIENT VOLTAGE SUPPRESSOR
ARRA
Y
VR-13
U601 IC,UNDERVOLTAGE SENSE CIRCUIT IC-1067
U603 PROGRAMMED ROM 2306-800B01
U604 IC,DUAL RETRIG MULTIVIB,74VHC123AMTC IC-1305
Y601 CRYSTAL,4MHZ CR-36-4M
Replaceable Parts 16-21
