16-22 Replaceable Parts
Table 16-7
Model 2306-VS analog board parts list
Circuit designation Description Keithley part no.
C400-C403,C405,C406,C411,C413,C4
18,
C420
CAP,.1UF,20%,50V CERAMIC C-418-.1
C404,C407,C604,C607 CAP,2200PF,10%,100V CERAMIC C-430-2200P
C408,C549,C608,C749 CAP,1000PF,20%,50V,MONO CERAMIC C-418-1000P
C409,C609 CAP,100PF,5%,100V CERAMIC C-465-100P
C410,C415,C543,C544,C610,C615,C44
6,
C531
CAP,.01UF,10%,50V CERAMIC C-491-.01
C412,C414,C416,C447,C449,C566,C61
2,
C614
CAP,47P,5%,100V,CERAMIC C-465-47P
C419,C523,C539,C619,C723,C739 CAP,22UF,20%,25V,TANTALUM C-440-22
C421-C424,C442,C448,C487,C529,C5
37,
C567
CAP,.1UF,20%,50V CERAMIC C-418-.1
C425,C426,C433,C443,C444,C445,C45
4,
C456
CAP,.1UF,10%,25V,CERAMIC C-495-.1
C427,C627 CAP,10U,20%,35V ALUMINUM C-562-10
C429,C784,C785,C663-C667,C685,C6
86,
C693
CAP,.01UF,10%,50V CERAMIC C-491-.01
C431,C432,C631,C632 CAP,1500P,20%,700V C-560-1500P
C434,C435,C634,C635 CAP,1000P,10%,100V CERAMIC C-451-1000P
C436,C464,C636 CAP,2.2U,10%,50V TANTALUM C-563-2.2
C438,C439,C440,C441,C557,C559,
C638-C641
CAP,22U,20%,25V TANTALUM C-535-22
C445,C454,C456,C457,C459,C462,C46
5,
C468
CAP,.01U,10%,25V CERAMIC C-495-.01
C450,C451,C650,C651 CAP,.47,10%,16V CERAMIC C-565-.47
C452,C652 CAP,.15UF,20%,50V,CERAMIC C-418-.15
C453,C653 CAP,.047U,10%,50V,CERAMIC
C-491-.047
C455,C458 CAP,33P,5%,100V,CERAMIC C-465-33P
C457,C459,C462,C465,C468,C469,C47
1,
C473
CAP,.1UF,10%,25V,CERAMIC C-495-.1
C460,C592,C681 CAP,22PF,10%,100V CERAMIC C-451-22P
C461,C683,C699,C684,C692,C796,
C689-C691
CAP,.1UF,20%,50V CERAMIC C-418-.1
C469,C471,C473,C474,C476,C484,C48
8,
C492
CAP,.01U,10%,25V CERAMIC C-495-.01
C474,C476,C484,C488,C492,C493,C54
0,
C569
CAP,.1UF,10%,25V,CERAMIC C-495-.1
