Replaceable Parts 16-29
R732,R628,R558,R560,R562,R577,R428,
R462
RES,10K,1%,100MW,THICK FILM R-418-10K
R753,R754,R459,R513 RES,10,10%,100MW,THICK FILM R-418-10
R768,R788,R702,R598 RES,10K,1%,100MW,THICK FILM R-418-10K
R781 RES,10K,1%,100MW,THICK FILM R-418-10K
RT400,RT401 THERMISTER,PD-7MW/DEG C,1500V,
613.74K
RT-8
RV400,RV600 TRANSIENT VOLTAGE SUPPRESSOR VR-19
RV401,RV601 VARISTOR VR-21
TP401,TP402-TP405,TP601-TP604,TP400 SURFACE MOUNT PCB TEST POINT CS-1026
TP406,TP407,TP600,TP605,TP606 SURFACE MOUNT PCB TEST POINT CS-1026
U400,U600 PROGRAM 2000-802A02
U401,U601 IC,QUAD D FLIP FLOP W/CLK,RESET,
74HC175
IC-923
U402,U403,U602,U603 IC,QUAD 2 IN NOR,74HCT02 IC-809
U404,U604 IC,NCHAN LAT DMOS QUADFET,
SD5400CY
IC-893
U405,U605,U455,U466,U643,U654 IC,OPA177GS IC-960
U406,U424,U436,U439,U464,U606,U623,
U636
IC,PRECICION BIFET OP-AMP IC-1194
U407,U607 IC,DUAL BIPOLAR OP-AMP,LT1124CS8 IC-955
U409,U609 IC,OP-AMP,NE5534D IC-802
U410,U435,U448,U461,U610,U648,U652,
U653
IC,VOLT COMPARATOR,LM311M IC-776
U411,U465 IC,OPAMP,LTC1150CS8 IC-1053
U412,U612 IC,HI SPEED MOSFET DRIVER,
MIC5021BN
IC-1333
U413,U457,U613 IC,INSTRUMENTATION AMPLIFIER IC-1165
U414,U415,U421,U423,U438,U614,U615,
U638
IC,20V,OP-AMP,LT1097S8 IC-767
U416,U616 IC,8-CHAN ANA MULTIPLEXER,
DG40
8DY
IC-844
U417,U452,U462,U617,U655 IC,8 STAGE SHIFT/STORE,MC14094BD IC-772
U418,U618 IC,CMOS ANALOG SWITCH IC-1210
U419,U619 IC,HIGH PRECISION 10V REFERENCE IC-1121
U420 IC,12 BIT DAC MULTIPLYING,
L
TC8143ESW
IC-1281
U422 IC,16 BIT DAC,LTC1595CCS8 IC-1277
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
