Keithley 2302 User Manual

16-30 Replaceable Parts
U426,U608,U453 IC,CMOS ANAL SWITCH,DG444DY IC-866
U427,U428,U430 IC,LOW POWER VIDEO OPAMP,
AD81
8AR
IC-1278
U429,U629 IC,INSTRUMENTATION AMPLIFIER,
IN
A128UA
IC-1125
U431,U432,U443,U631,U632 IC,VOLT COMPRATOR,LM393D IC-775
U433,U621 IC,+5V 10 BIT DAC,MAX515CSA IC-1331
U434,U624,U451,U468,U470,U651 IC,DUAL OP AMP,LF353M IC-842
U437,U442,U637,U642 IC,VOLTAGE REFERENCE SOIC8 IC-1065
U440,U622 IC,1000V,OPAMP,LT1363CS8 IC-1279
U441,U641 IC,PWR OUTPUT STAGE BIAS SYS,
L
T1166CS8
IC-1159
U444,U625,U469,U471 IC,VOLT COMPARATOR,LM311M IC-776
U445 IC,VOLTAGE REGULATOR,LM317T IC-317
U446,U646 IC,POS NAND GATES/INVERT,74HCT41 IC-656
U447,U647 IC,12-BIT VOLTAGE OUTPUT DAC IC-1130
U449 IC,20V,OP-AMP,LT1097S8 IC-767
U450,U650 IC,SYNCHRONOUS DC/DC
CONTROLLER
IC-1255
U454 IC,HI-SPEED BIFET OP-AMP,AD711JR IC-894
U456,U626 IC,DUAL D-TYPE F/F,74HC74 IC-773
U458 IC,HIGH SPEED OPAMP OPA603AP IC-1302
U459 IC,DIFET OPAMP,OPA671AP IC-1299
U460 IC,TINYLOGIC CMOS INVERTER IC-1282
U463,U467 IC,8 BIT MULTIPLYING DAC DAC08CS IC-1298
U611 IC,DUAL +/-15V ZERO DRIFT OPAMP IC-1126
U620 IC,DUAL 12-BIT MDAC IC-1122
U639,U425 IC,PRECICION BIFET OP-AMP IC-1194
U645 IC,VOLTAGE REG LM317M IC-846
VR400,VR401,VR600,VR601 DIODE,ZENER,6.2V,MMSZ6V2 DZ-97
VR402,VR602 DIODE,ZENER 6.44V,1N4577AGED DZ-58
VR403,VR410,VR411,VR603,VR607,
VR608
DIODE,ZENER 17V,MMBZ5247BL DZ-104
VR404,VR604,VR413,VR414 5.1 VOLT ZENER DIODE DZ-121
VR405,VR406,VR605,VR606 DIODE,ZENER 12V,MMSZ12T1 DZ-112
VR407 DIODE,ZENER 3V,CMPZ4619 DZ-118
VR408,VR409 DIODE,ZENER 3.3V,MMBZ5226BL DZ-94
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
