Replaceable Parts 16-31
VR412,VR610 DIODE,ZENER,3.3V,CMPZ4684 DZ-115
VR609 DIODE,ZENER 17V,MMBZ5247BL DZ-104
Y400,Y600 OSCILLATOR HIGH SPEED
C
MOS,12MHZ
CR-37
Table 16-8
Model 2306-VS mechanical parts list
Qty. Description Keithley part no.
1 BEZEL,REAR 428-303D
2 CABLE ASSEMBLY CA-211-1A
1 CABLE ASSEMBLY CA-212-1A
1 CABLE ASSEMBLY CA-213-1B
1 CONN,FEMALE,3PIN,SHAPELESS CS-287-3
2 CONNECTOR CS-236
2 CONNECTOR CS-276
4 CONNECTOR CS-627
4 CONNECTOR,BNC CS-249
1 CONNECTOR,HOUSING CS-638-3
1 FAN FN-34-3
2 FOOT 428-319A
2 FOOT,EXTRUDED FE-22A
2 FOOT,RUBBER FE-6
1 FUSE,EXP.2A/5X20MM S-B FU-81
1 HANDLE 428-329F
1 LINE CORD CO-7
1 LINE FILTER LF-11
1 MOUNTING EAR,LEFT 428-338B
1 MOUNTING EAR,RIGHT 428-328E
1 POWER ROD 704-313A
1 PRINTED FRONT PANEL V-2306-306A
Table 16-7
Model 2306-VS analog board parts list (cont.)
Circuit designation Description Keithley part no.
