Keithley 2302 User Manual

1-12 Getting Started
Table 1-2
Factory defaults (RST)
Setting
Reset (RST) default
Battery Channel (#1) Charger Channel (#2)
Output value settings:
Voltage (V) 0.000V 0.000V
Current (A) 0.2500A 0.2500A
Output state (operate) OFF OFF
Voltage protection 8V, clamp off 8V, clamp off
Display type Actual V and I Actual V and I
GPIB address* No effect (factory set to 16)
Current range 5 amps (Auto Range OFF) 5 amps (Auto Range OFF)
Integration rate 1.00 PLC 1.00 PLC
Average readings 1 1
Power on setup* No effect (factory set to RST)
Current limit mode LIM LIM
Output relay one*
Output relay two*
Output relay three*
Output relay four*
No effect (after power
cycle, set to zero)
VFD brightness* Over bus: 1 From display: FULL BRI
GHTNESS
Output bandwidth LOW** HIGH
Output impedance 0.00Ω Not Applicable
Pulse current:
High time 33 µsec 33 µsec
Low time 33 µsec 33 µsec
Average time 33 µsec 33 µsec
Digitize time 33 µsec (B10 or later) 33 µsec (B10 or later)
Timeout 1.000 sec 1.000 sec
Average readings 1 1
Trigger delay 0.00000 sec 0.00000 sec
Trigger level:
Range
Model 2306, 2306-VS,
and 2306-PJ Model 2306-PJ
5A Current range 500mA Current range
5A (Full scale) 500mA (Full scale)
5A 0.000A 500mA 0.0000A
1A 0.000A 100mA 0.0000A
100mA 0.0000mA 10mA 0.0000A
Model 2306/2306-VS & 2306-PJ
Not Applicable
0.000A
Not Applicable
Not Applicable
Step Off
Step up 1
Step down 1
Step time 200µs
Step timeout 2ms
