1-16 Getting Started
TRIGGER LEVEL Model 2306, 2306-VS and 2306-PJ — Sets pulse current trig-
ger level in Amps on the 5A current range:
Battery channel (#1) Charger channel (#2)
A(5.0) 0–5A A(5.0) 0–5A
A(1.0) 0–1A
mA(100) 0–100mA
LONG INTEGRAT #1/#2 Long integration configuration. Sect. 4
INTEGRATION TIME
AUTO TIME
PULSE TIMEOUT
TRIGGER EDGE
TRG LEV mA RANGE
TRG LEVEL mA
TRIG LEV RANGE
TRIGGER LEVEL
Manually set integration time (up to 60 sec).
Automatically set integration time.
Set the “NO PULSE” timeout period (1 to 63 sec).
Select trigger edge (rising
, falling or neither).
Model 2306-PJ — Set battery channel (#1) trigger level range
o
n the 500mA current range (500mA, 100mA, 10mA).
Model 2306-PJ — Set pulse current trigger level in mA on the
5
00mA current range:
Battery channel (#1) Charger channel (#2)
mA(500mA) 0–500mA Use TRIGGER LEVEL menu
mA(100mA) 0–100mA item (charger channel supports
mA(10mA) 0–10mA 5A current range only)
Model 2306, 2306-VS and 2306-PJ — Set battery channel (#1)
trigge
r level range (5A, 1A, 100mA) on the 5A current range.
Model 2306, 2306-VS and 2306-PJ — Sets long integration
trigge
r level in Amps on the 5A current range:
Battery channel (#1) Charger channel (#2)
A(5.0) 0–5A A(5.0) 0–5A
A(1.0) 0–1A
mA(100) 0–100mA
Notes: 1. See “Default settings” on page 1-11 in this section to save and recall setups. For Models 2306-PJ and 2306-VS, the
memory location settings availabl
e are from SAV0-SAV2 (SAV3 and SAV4 are not available).
2. Revision Number displays the firmware revision le
vel for the microcontroller and the display.
3. Serial Number displays the serial number of the power supply.
Table 1-3 (cont.)
Main MENU structure (accessed by pressing the MENU key on the Front Panel)
Menu item Description Ref
