IEEE-488 Reference
5-44
2. Semantic error: Model 7001 received a command that was misspelled, or received an op-
tional IEEE-488.2 command that is not implemented.
3. The instrument received a Group Execute Trigger (GET) inside a program message.
Bit B6, User Request (URQ)
Set bit indicates that the LOCAL key on the Model 7001 front
panel was pressed.
Bit B7, Power On (PON)
Set bit indicates that the Model 7001 has been turned off and
turned back on since the last time this register has been read.
10 OUTPUT 707; “*ESE?” ! Request register value
20 ENTER 707; A$ ! Address 7001 to talk
30 PRINT A$ ! Display value
Programming
example
Figure 5-14
Standard Event Status Register
B7 B6 B5 B4 B3 B2 B1 B0
0/1 0/1 0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Event Bit Set
0 = Event Bit Cleared
Events : PON = Power On
URQ = User Request
CME = Command Error
EXE = Execution Error
DDE = Device-dependent Error
QYE = Query Error
OPC = Operation Complete
PON URQ CME EXE DDE QYE OPC
0/1 0/1 0/1 0/1
(2 )
7
(2 )
6
(2 )
5
(2 )
4
(2 )
3
(2 )
2
(2 )
0
64 32 1128 16 8 4
