Front Panel Operation
4-27
4. When finished, press EXIT to return to the DIGI-
TAL I/O MENU.
INPUT-STATUS
Use this menu item to read (on or off)
the digital input channel. Polarity is fixed at active-
high (ON = 5V).
To select INPUT-STATUS, place the cursor on INPUT-
STATUS and press ENTER. If for example, the digital
input channel is “on”, the following message will be
displayed:
DIGITAL INPUT LINE
Status = ON
Press ENTER or EXIT to return the instrument to the
Digital I/O Menu.
4.6.4 TEST
The TEST menu is to be used as a diagnostic tool to iso-
late problems with the Model 7001. Refer to Section 7
Maintenance for information on using these test proce-
dures.
4.6.5 LANGUAGE
The LANGUAGE menu is used to change the language
for display messages. Language selections include:
• Display messages in ENGLISH.
• Display messages in GERMAN.
• Display messages in FRENCH.
Perform the following steps to change the language of
menu display messages:
1. Display the MAIN MENU (see paragraph 4.6, Gen-
eral rule #1).
2. Use the cursor keys ( and ) to place the cursor
on LANGUAGE and press ENTER. The following
language menu selections will be displayed:
CHOOSE MENU LANGUAGE
ENGLISH GERMAN FRENCH
The cursor will be located on the currently selected
language. Note that if a language other than En-
glish is currently selected, the menu will be dis-
played in the selected language.
3. To retain the currently selected language, press
EXIT or ENTER. The display will return to the
MAIN MENU.
4. To select one of the other languages, place the cur-
sor on the desired language selection and press
ENTER. The instrument will return to the MAIN
MENU.
Note: The selected language becomes the power-
up default.
4.6.6 GENERAL
The GENERAL MENU is used for the following oper-
ations:
• Serial # of the Model 7001.
• SCPI version control number.
• Software revision level installed in the Model 7001.
• Select the Status Message Mode.
Perform the following steps to display the GENERAL
MENU:
1. Display the MAIN MENU (see General Rule #1,
paragraph 4.6).
2. Use the cursor keys ( and ) to place the cursor
on GENERAL and press ENTER. The following
menu will be displayed:
GENERAL MENU
SERIAL # STATUS-MESSAGES
SERIAL #
To display the serial number, SCPI version
and software revision level of the instrument, place the
cursor on SERIAL # and press ENTER. The following
information will be displayed:
Serial #XXXXXX
SCPI version #XXX.X software rev AXX/AYY
