General Information
1-2
form at the back of this manual in order to provide the
repair facility with the necessary information.
1.4 Manual addenda
Any improvements or changes concerning the instru-
ment or manual will be explained in an addendum in-
cluded with the manual. Be sure to note these changes
and incorporate them into the manual.
1.5 Safety symbols and terms
The following symbols and terms may be found on an
instrument or used in this manual.
The symbol on an instrument indicates that the
user should refer to the operating instructions located
in the instruction manual.
The symbol on an instrument shows that high
voltage may be present on the terminal(s). Use stan-
dard safety precautions to avoid personal contact with
these voltages.
The
WARNING
heading used in this manual explains
dangers that might result in personal injury or death.
Always read the associated information very carefully
before performing the indicated procedure.
The
CAUTION
heading used in this manual explains
hazards that could damage the scanner card. Such
damage may invalidate the warranty.
1.6 Specifications
Model 7001 speciÞcations may be found at the front of
this manual.
1.7 Inspection
The Model 7001 was carefully inspected, both electri-
cally and mechanically before shipment. After unpack-
ing all items from the shipping carton, check for any
obvious signs of physical damage that may have oc-
curred during transit. Report any damage to the ship-
ping agent immediately. Save the original packing
carton for possible future reshipment. The following
items are included with every Model 7001 order:
¥ Model 7001 Switch System
¥ Model 7001 Instruction Manual
¥ Accessories as ordered.
If an additional instruction manual is required, order
the manual package, Keithley part number 7001-901-
00. The manual package includes an instruction manu-
al and any pertinent addenda.
1.8 Optional accessories
The following accessories are available from Keithley
for use with the Model 7001.
Model 4288-1 Single Fixed Rack Mount Kit;
mounts a
single Model 7001 in a standard 19-inch rack.
Model 4288-2 Dual Fixed Rack Mount Kit;
mounts
two Model 7001s side-by-side in a standard 19-inch
rack.
Model 4288-3 Dual Fixed Rack Mount Kit;
mounts
one Model 7001 and a Model 199 DMM side-by-side in
a standard 19-inch rack.
Model 8502 Trigger Link Adapter;
allows you to con-
nect the Trigger Link of the Model 7001 to an instru-
ment that uses the standard BNC (In/Out) external
triggering technique.
!
