Keithley 7001 User Manual

IEEE-488 Reference
5-106
Effects of positive transitions on the Trigger Event Register:
Positive Transition Effect On
Trigger Event Trigger Event Register
Sequence 1 Sets B1 when waiting in Trigger Layer.
Figure 5-26
Trigger Transition Filter
(B15 - B2) B1 B0
(2 )
1
2
0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Enable Positive Transition
0 = Disable Positive Transition
A) Positive Transition (PTR) Register
Seq1
(B15 - B2) B1 B0
0/1
Bit Position
Event
Decimal Weighting
Value
Value : 1 = Enable Negative Transition
0 = Disable Negative Transition
B) Negative Transition (NTR) Register
Seq1
(2 )
1
2
:STATus Subsystem
