Keithley 7001 User Manual

Replaceable Parts
Table 8-3
Micro DIN Board, Parts List
Circuit
desig. Description
Keithley
part no.
C602-612
C601
CR600-610
J1007-1009
J1010
P1003
R600-604
R606-614
R615
U601
MICRO DIN AND BNC BOARD ASSEMBLY
CAP,270PF,20%,100V,CERAMIC/FERRITE
CAP,.1UF,20%,50V,CERAMIC
DIODE,SILICON,1N4148 (DO-35)
CONN, CIRCULAR DIN
LATCHING HEADER,FRICTON, SGL ROW
CONNECTOR, PIN STRIP
RES,10,1%,1/8W,METAL FILM
RES,10K,1%,1/8W,METAL FILM
RES,2K,1%,1/8,METAL FILM
IC,8-CHANNEL SAT SINK DRIVER,UDN-2596A
7001-250
C-386-270P
C-365-.1
RF-28
CS-762
CS-724-3
CS-776-28
R-88-10
R-88-10K
R-88-2K
IC-578
8-7
