SECTION 1. NAMES OF PARTS
Cabinets and Sewing Machine Tote Bag
(RSOS #97611) (U.S.A. Only)
Sewing machine cabinets and tote bag are available
through the RSOS (Retail Special Oder System) cata=
log at your nearest Sears store.
Names of Parts
Mode selecting key
Down (-) key
Up (+) key
LED display
Spool holder (large)
Spool pin
Bobbin winding thread guide
_) Thread guide
Thread take-u
Thread tens
(_) Face plate
Thread
Automatic
@ Needle plat_
Extension table
_6) Hook cover
Hook cover release button
@) Stitch balance adjusting dial
Reverse stitch button
Auto-lock button
_) Up/Down needle position button
Speed control lever
Needle clamp screw
@ Needle
Presser foot
_6_ Foot holder
Carrying handle
@ Bobbin winding spindle
Bobbin winder stopper
Handwheel
@ Power switch
@ Machine socket
Drop feed lever
@ Free arm
@ Buttonhole lever
Presser foot lifter
@ Hole for additional spool pin
NOTE: prior notice.
The specifications are subject to change without
®
@
®
@
\
\\
@
@
To Next Page
