Dropping the Feed Dog
The feed dog can be lowered by the drop feed lever
for sewing on buttons, manual embroidery etc.
Push the drop feed lever to the right to lower the feed
dog.
Push the lever to the left to raise the feed dog; it will
return to the up position when starting the machine.
NOTE:
The feed dog should be in up position for normal
sewing. Turn the handwheel toward you to check if
the feed dog comes up after setting the lever in the
up position.
_i_ Down position
_2_Up position
_3_ Feed dog
_3_Highest position
