Threading the Machine
Threading the machine
_i_Spool
_2_Spool holder
_3_Presser foot lifter
[iq Raise the presser foot.
Press the Up/Down needle
bring the take-up lever to its
Turn the power switch OFF.
Draw the end
hook aroun(
the thread
the
_4_Upper
_5_Slot
[21Draw the end around the thread
guide plate and draw it up to the left.
Make sure the thread slips in between the tension
disks.
_6_Thread guide plate
_7_Tension disks
[31Firmly draw the thread up to the take-up lever,
and down into the eye of the thread take-up lever
from the right to left.
_8_Thread take-up lever
[3 Pass the thread in the lower thread guide from the
right.
_9_Lower thread guide
[5] Slip the thread in the needle bar thread guide on
the left.
_# Needle bar thread guide
NOTE:
Refer to page 28 for the automatic needle threader.
