Front-Panel Operation 2
Keysight 34420A Service Guide 53
Menu Example 1
The following steps show you how to turn on the menu, move up or down
between levels, move across the choices on each level, and turn off the menu.
In this example, you will turn off the display comma separator.
The meter can display readings on the front panel with or without a comma
separator. The following steps show how to disable the comma.
1 Turn on the menu.
You enter the menu on the menus level. The MEAS MENU is your first choice
on this level.
2 Move across to the SYS MENU choice on this level.
There are six menu group choices available on the menus level. Each choice
has a letter prefix for easy identification (A: , B: , etc.).
-0.824,153 V -0.824153 V
With comma separator
(factory setting)
Without comma separator
To Next Page
