Front-Panel Operation 2
Keysight 34420A Service Guide 69
Chart Output (Analog Output)
You can use the Chart Output (Analog Output) connector on the rear panel to run
a strip chart recorder or similar instrument. The connector provides an output
voltage proportional to the measured voltage.
Enable the chart output under the 5: CHART OUT command in the SYStem
menu.
Set the chart span under the 6: CHART SPAN command in the SYStem menu.
Set the chart offset under the 7: CHART NULL command in the SYStem menu.
You can also press (Chart Null) to null the chart output voltage
based upon the displayed reading. This action places a null value in the Chart
Offset register. Pressing
(Menu Recall) will take you to the
7: CHART NULL command where you can manually edit the null value.
The output can range from –3.00 V to +3.00 V.
When chart output is disabled (Off), the output is set to 0 V.
The output impedance is 1 kW.
The output voltage is related to the input signal as follows:
Note that reading includes the results of measurement unit conversion,
filtering, null, and any math operation performed on the measurement.
The chart output state (including the span and null values) is stored in
non-volatile memory.
span cannot have a negative value.
The chart output has a voltage “rollover” to prevent the loss of data, see the
Keysight 34420A User’s Guide.
Shift
Null
Shift
reading chart null()
span
----------------------------------------- chart output voltage=
