Keysight N5221A/22A Service Guide 2-5
General Product Information
Required Service Test Equipment
Required Service Test Equipment (Cont’d)
Required Service Test Equipment (Cont’d)
Equipment
a
Critical Specifications Recommended
Model or Part
Number
Alternate Model
or Part Number
Use
b
Calibration and Verification Kits
3.5 mm calibration kit Freq: 10 MHz to 26.5 GHz 85052B 85052D P,T,V
3.5 mm verification kit Freq: 10 MHz to 26.5 GHz 85053B None V
Cables
BNC cable (2 required) 50 Ω, length ≥ 60 cm 8120-1839 None A
3.5 mm RF cable (Qty 2) 50 Ω, length ≥ 60 cm 85131C 85131E P,A,V
GPIB cable N/A 10833A/B/C/D None P,A
Adapters
3.5 mm (f) to 3.5 mm (f) Return Loss: ≥ 32 dB 83059B
85052-60012
c
P, A , T
3.5 mm (f) to type-N (m) Return Loss: ≥ 28 dB 1250-1743 None P,A,T
Attenuators
3.5 mm (m,f), 10-dB fixed
attenuator
Accuracy: ± 0.5 dB
Freq: 10 MHz to 26.5 GHz
8493C
Option 010
None P
3.5 mm (m,f), 20-dB fixed
attenuator
Accuracy: ± 0.5 dB
Freq: 10 MHz to 26.5 GHz
8493C
Option 020
None P
a. Unless specified otherwise, equipment listed is required for all analyzer models.
b. P = Performance tests, A = Adjustments, T = Troubleshooting, R = Repair, V = System verification
c. Included in the 85052B/D calibration kits.
Equipment
a
Critical Specifications Recommended
Model or Part
Number
Alternate
Model
Number
Use
b
Tools
T-8 TORX driver 0.6 N-m (5 in-lb) setting N/A N/A R
T-10 TORX driver 0.5, 0.8, and 1.0 N-m
(4, 7, and 9 in-lb) settings
N/A N/A T, R
T-15 TORX driver 1.5 N-m (14 in-lb) setting N/A N/A T, R
T-20 TORX driver 2.4 N-m (21 in-lb) setting N/A N/A T, R
1/4 inch and 5/16 inch open-end
wrench
Thin profile 8710-0510 N/A A, R
