3-2 Installation and Service Guide N5250-90001
System Installation
Receiving the System
PNA Series Microwave Network Analyzer System
N5250A
Receiving the System
The N5260A millimeter head controller and the test head modules are sensitive
to electrostatic discharge (ESD). Ground your work station before unpacking
and installing
the test head modules. See “Electrostatic Discharge Protection”
on page 1-4.
The System as Shipped
The N5250C system components will arrive packaged separately. For a complete list of
components shipped with your system, refer to Table 3-1 on page 3-3.
When the entire shipment has arrived, contact Keysight Technologies to arrange for system
installation, if installation is available in your area. See “Keysight Support, Services, and
Assistance” on page 5-4.
Keep the shipping containers until the system checklist has been completed, and the system has
been checked for physical damage.
If the shipping container is damaged or the packaging material shows signs of stress, notify the
carrier as well as the Keysight Technologies Customer Engineer. Keep the shipping materials for
the carrier’s inspection. Keysight Technologies will arrange for repair or replacement of
damaged equipment without waiting for a claim settlement from the carrier. Refer to “Keysight
Support, Services, and Assistance” on page 5-4.
Keysight Technologies Customer Engineering
A Keysight Technologies Customer Engineer will be assigned to help you install the system.
During installation, the Customer Engineer will do the following:
• Unpack the system components
• Complete the system checklist, see Table 3-1 on page 3-3.
• Connect the E8361C H11 PNA and the N5260A millimeter head
controller.
• Install the millimeter-wave test head modules.
• Run a performance verification of the system, which includes a
measurement calibration.
• Provide user training for one engineer.
