Keysight Technologies N5250C PNA Series User Manual

Installation and Service Guide N5250-90001 3-3
System Installation
Receiving the System
PNA Series Microwave Network Analyzer System
N5250A
System Contents
Use the table below to verify that the shipment is complete. These are items that are
supplied with all N5250C complete systems only.
Table 3-1
N5250C System Contents
✔
Keysight
Part Number Qty Description
N5250C-700
(Standard)
0 or 1
Vector network analyzer system, 10 MHz
to 110 GHz, 1.0 mm (m) test ports
Includes:
E8361C H11 PNA, N5260A millimeter head
controller, N5260A-110 millimeter-wave test
head modules, port 1 attenuator, and cables
N5250C-017
(Option 017)
0 or 1
Vector network analyzer system, 10 MHz to
110 GHz, 1.0 mm (m) test ports
Includes:
E8361C H11 PNA, N5260A millimeter head controller,
N5260A-120 millimeter-wave test
head modules with
bias-tees, port 1 attenuator, and cables
N5250C-018
(Option 018)
0 or 1
Vector network analyzer system, 10 MHz to
110 GHz, 1.0 mm (m) test ports
Includes:
E8361C H11 PNA, N5260A millimeter head controller,
N5260A-120 millimeter-wave test head modules with
bias-tees, port 1 and 2 attenuators, and cables
E8361C H11
Includes:
1
PNA series microwave vector network analyzer
(10
MHz to 67 GHz)
E8361C Option H11 1 IF Access
E8361C Option 014 1 Configurable test set
E8361C Option UNL 1 Source Attenuators and Bias-Tees
E8361C Option 080 1 Frequency Offset
E8361C Option 081 1 Reference Channel Switch
E8356-90001 1
PNA Series Network Analyzer Installation
and Quick Start Guide
N5260A
1 Millimeter Head Controller
Includes:
85105-60030 2 Bias Cable (48” length)
85105-60033 4 IF Signal Cable (48” length)
8121-1221 4 RF and LO 3.5 mm Cable (48” length)
8120-6818
(was 08503-60051)
1 Test Set Interface Cable
8120-1839 4 IF Signal Cable
5061-9038 2 RF and LO SMA Cable
