Keysight Technologies N5250C PNA Series User Manual

4-4 Installation and Service Guide N5250-90001
System Specifications
Specifications
PNA Series Microwave Network Analyzer System
N5250A
General E8361C/C Option H11 Specifications
The E8361C Option H11 specifications are identical to the specifications
given for the E8361C Option UNL, 080, 081, and 014 in the E8361C data
sheet.
E8361C Option H11 Rear Panel Specifications
b. Assumes a 30 inch cable from
the PNA Source Out bulkhead connector is used to provide the 10 MHz to 67 GHz
source signal. The Option 017 and 018 configurations includes a bias-tee in the 1.0 mm test head and use this
connection.
Table 4-2 General E8361C/C H08 and H11 Rear Panel Specifications
IF Connectors A, R1, R2, B
IF Connector Input Frequency 8.333 MHz
0.1 dB Compression Points at IF inputs
–27.0 dBm
Pulse Input Connectors
a
A, R1, R2, B (BNC connectors)
Drive Voltage TTL (0, +5.0) Volts
Nominal Input Impedance at IF Inputs 50 Ohms
RF Damage Level to IF Connector Inputs
–20.0 dBm
DC Damage Level to IF Connector Inputs 25 Volts
Nominal Input Impedance at Pulse Inputs 1 Kohm
Minimum IF Gate Width 20 ns for less than 1 dB
deviation from theoretical
performance
b
DC Damage Level to Pulse Connector Inputs 5.5 volts
Rear Panel LO Power - Test Port Frequency
(see 836x H11 PNA Specifications for test port frequencies up to 67 GHz)
67 GHz to 110 GHz
c
-7 to -13 dBm
Rear Panel RF Power - Test Port Frequencies
(see 836x H11 PNA Specifications for test port frequencies up to 67 GHz)
-4 to -10 dBm
67 GHz to 76 GHz
d
76 GHz to 96 GHz
d
96 GHz to 110 GHz
d
+1 to -5 dBm
+5 to -1 dBm

Keysight Technologies N5250C PNA Series Specifications

General

Brand	Keysight Technologies
Model	N5250C PNA Series
Category	Measuring Instruments
Language	English
