Installation and Service Guide N5250-90001 7-3
PNA Series Microwave Network Analyzer System
N5250A
Replaceable Parts
Replaceable Parts
R
eplaceable Parts
Table 7-1 Replaceable Parts List
Keysight
Part Number
Description
Waveguide Modules:
N5260-69003
67 GHz to 110 GHz waveguide T/R module with attenuator. Exchange is available
only when the customer’s module is returned to the factory for service.
N5260-69004
67 GHz to 110 GHz waveguide T/R module without attenuator. Exchange is available
only when the customer’s module is returned to the factory for service.
Combiner Assembly Parts:
N5260-60005 WR-10 2-inch long waveguide section
1390-0765 4-40 captive screw (waveguide flange)
2190-0556 4-40 split-lock washer (waveguide flange)
N5260-00007 Bracket—right combiner assembly
N5260-00008 Bracket—left combiner assembly
0515-0372 M3.0 x 8 mm screw (bracket)
85104-60061 1.0 mm test port connector
2190-0104 Washer (for 1 mm test port connector)
2950-0132 Nut (for 1 mm test port connector)
2110-0046 Fuse (inch) 0.5A, 125V NTD BI. Fuse for bias tee (option 017 and 018)
System Front Cables:
8121-1221 N5260A mill
imeter head controller RF and LO 3.5 mm cable (48” length)
85105-60033 N5260A millimeter head controller IF signal cable (SMA) (48” length)
85105-60030 N5260A millimeter head controller bias cable (
48” length)
8121-1233 E8361C PNA front panel access port RF 1.85 mm (m)-(m) cable (30” length)
N5260-60009 E8361C PNA front panel test port RF 1.85 mm (f)-(m)
cable (Option 700) (30” length)
1250-2604 SMA right angle adapter (Used only with 8121-1221 cable.)
System Rear Cabl
es:
8120-1839 N5260A millimeter head controller IF signal cable (BNC)
8120-6818
(was 08503-60051)
N5260A millimeter head controller test set interface cable
