3-4 Installation and Service Guide N5250-90001
PNA Series Microwave Network Analyzer System
N5250A
1250-2604 4
SMA Right Angle Adapter (Not required unless
needed with 8121-1221 cables.)
5063-9226 1 Handle Set
5063-9232 1 Rack Mount Flange Set
N5250C-90001 1 Installation and Service Guide
N5260A-110
(Standard)
0 or 1
millimeter-wave test head modules, port 1
attenuator, 67 GHz to 110 GHz, 1 mm (m) test ports
Includes:
N5260-60007
Includes:
1 Left millimeter-wave test head
N5260-60002 1 Left combiner assembly
N5260-60003 1
67 GHz to 110 GHz Wave Guide T/R
Module with Attenuator
N5260-60006
Includes:
1 Right millimeter-wave test head
N5260-60001 1 Right combiner assembly
N5260-60004 1 67 GHz to 110 GHz Wave Guide T/R Module
N5260-60009 2
PNA Front Panel Test Port RF 1.85 mm (f)-(m)
Cable (30” length)
8121-1233 2
PNA Front Panel Access Port RF 1.85 mm (m)-(m)
Cable (30” length)
N5260A-120
(Option 017)
0 or 1
Millimeter-wave test head modules with bias-tees,
port 1 attenuator, 67 GHz to 110 GHz, 1mm (m) test
ports
Includes:
N5260-60011
Includes:
1 Left mil
limeter-wave test head with bias-tee
N5260-60013 1 Left combiner assembly with bias-tee
N5260-60003 1
67 GHz to 110 GHz Wave Guide T/R
Modul
e with Attenuator
N5260-60010
Includes:
1 Right millimeter-wave test head with bias-tee
N5260-60012 1 Right combiner assembly with bias-tee
N5260-60004 1 67 GHz to 110 GHz Wave Guide T/R Module
8121-1233 4
PNA Front Panel Access Port RF 1.85 mm (m)-(m)
Cable (30” length)
N5260A-130
(Option 018)
0 or 1
Millimeter-wave test head modules with bias-tees,
port 1 and 2 attenuators, 67 GHz to 110 GHz, 1mm
(m) test ports
Includes:
System Installation
Receiving the System
Table 3-1
N5250C System Contents (Continued)
