Current and voltage Arbs share settings, so setting the current Arb resets the voltage Arb level to its
default value and vice versa. For better performance, the list can be sent as single precision floating
point values in definite length arbitrary block format instead of an ASCII list. The response format is
dependent on the return format ASCII or REAL.
Parameter Typical Return
-10.2% to 102% of current rating or
0 to 102% of voltage rating
<value> [,<value>]
or
<Block>
With power dissipator:
up to -102% to 102% of current rating
Programs a constant dwell Arb of 5 voltage points:
ARB:VOLT:CDW 5,4,3,2,1
[SOURce:]ARB:CURRent:CDWell:DWELl <value>
[SOURce:]ARB:CURRent:CDWell:DWELl?
[SOURce:]ARB:VOLTage:CDWell:DWELl <value>
[SOURce:]ARB:VOLTage:CDWell:DWELl?
Specifies the dwell time of each point in the Arb. Values are in seconds and are rounded to the nearest
10.24-microsecond increment.
Current and voltage Arbs share settings, so setting this parameter for a current Arb changes the
voltage dwell value and vice versa.
Parameter Typical Return
0.00001024 – 0.30, *RST 0.001 <dwell value>
Programs a constant dwell time of 0.2 seconds:
ARB:CURR:CDW:DWEL 0.2
[SOURce:]ARB:CURRent:CDWell:POINts?
[SOURce:]ARB:VOLTage:CDWell:POINts?
Returns the number of points in the Arb.
Parameter Typical Return
(none) <points>
Returns the number of current points in the Arb:
ARB:CURR:CDW:POIN?
Keysight N6900/N7900 Series Operating and Service Guide 212
6 SCPI Programming Reference
