Chapter 1 23
Introducing the N8241/2A AWGs
Graphical User Interface (GUI)
Graphical User Interface (GUI)
The tab-based graphical interaction of the GUI gives instant access to the AWG
parameters, making it easy to configure signal output. Each tab is labeled with its
contents, enabling quick access to all functions. Figure 1-3 displays the first level of
the GUI. For more information on the GUI, refer to the N8241A Online Help.
Access this from the application Help menu, or in Windows:
Start > Programs > Agilent > N8241A > Help.
Figure 1-3 N8241A Control Utility
