53210A Math, Graphing, and Data Logging 6
Keysight 53210A User’s Guide 185
Data Logging
The data logging feature of the 53210A counter allows you to log and analyze up
to 1,000,000 readings. Data logging is enabled and configured from the front
panel only, and is available with all counter measurements except continuous
totalizing.
Figure 6-11 shows the keys and windows associated with the data logger
application.
Figure 6-11 Starting the Counter Data Logger.
Logged readings ARE NOT saved to internal flash memory or external USB
memory until the logging duration is complete. If power is lost and if battery
Option 300 is not enabled or it also loses power before logging is complete, all
data will be lost.
