53210A Software Installation and Interface Configuration 2
Keysight 53210A User’s Guide 67
Configuring the GPIB Interface
Programming access to the 53210A is also available through the GPIB interface.
GPIB cables can be connected to the PC in a “star” (all cables connect directly to
the computer) or “linear” (instrument to instrument) configuration.
Adding Instruments to the GPIB Configuration
To add instruments to the GPIB interface, click and select GPIB Instrument
on the Connection Expert tool bar (Figure 2-4). In the Add a GPIB Instrument
window that appears (Figure 2-7), select the counter’s GPIB address (note:
factory-set address = 3) and select OK.
Connection Expert will attempt to establish a communication path to the
instrument. If the counter is at the address specified, the instrument will be added
to the list of GPIB-configured instruments.
The following information assumes a GPIB card or USB/GPIB interface is present
on your computer.
