Table 3-2 Counter Configuration using CONFigure and MEASure
Parameter CONFigure/MEASure Setting Low-Level Command/Subsystem
Input
range, low-pass filtering, coupling,
impedance and noise rejection are
unchanged from previous or their
power-on settings.
INPut{[1]:RANGe
INPut[1]:FILTer
INPut[1]:COUPling
INPut[1]:IMPedance
INPut[1]:NREJect
Trigger source IMMed iate TRIGger:SOURce
Trigger slope NEGative TRIGger:SLOPe
Trigger delay 0.0 seconds TRIGger:DELay
Trigger count 1 trigger TRIGger:COUNt
Sample count 1 sample SAMPle:COUNt
GATE Source
Based on measurement function
specified by the CONFigure or
MEASure command.
SENSe:FREQuency:GATE:SOURce
External Gate Source Gate In/Out BNC OUTPut:STATe
Math
Graphics
Disabled, including the individual
calculate functions. Other
parameters are unchanged.
CALCulate1 subsystem
CALCulate2 subsystem
Auto-level Frequency Unchanged SYSTem:ALEVel:FREQuency
Measurement Timeout Unchanged SYSTem:TIMeout
Reference oscillator
Unchanged from previous settings.
SENSe:ROSCillator:SOURce
SENSe:ROSCillator:SOURce:AUTO
SENSe:ROSCillator:EXTernal:FREQu
ency
Reading Format
Data Storage
Instrument Status
Unchanged from previous settings.
Unchanged from previous settings.
Unchanged from previous settings.
FORMat Subsystem
DATA Subsystem
STATus Subsystem
