Performance Specifications
Table 8-1 Performance specifications
Parameter Keysight E3633A Keysight E3634A
Output Ratings
(@ 0
°C- 40 °C)
Low Range 0 to +8 V/ 0 to 20 A 0 to 25 V/ 0 to 7 A
High Range 0 to +20V/ 0 to 10 A 0 to+50 V/ 0 to 4 A
Programming Accuracy
[a]
12 months (@ 25 °C ± 5 °C),
±(% of output + offset)
[a] Accuracy specifications are after an 1-hour warm-up with no load and calibration at 25 °C.
Voltage 0.05% + 10 mV
Current 0.2% + 10 mA
Readback Accuracy
[a][b]
12 months (over GPIB and
RS-232 or front panel with
respect to actual output @ 25 °C
± 5 °C), ±(% of output + offset)
[b] This specification may degrade when the unit is subjected to an RF field >= 3V/meter.
Voltage 0.05% + 5 mV
Current 0.15% + 5 mA
Ripple and Noise
(with outputs ungrounded, or
with either output terminal
grounded, 20 Hz to 20 MHz)
Normal mode voltage <0.35 mV rms and
3 mV p-p
<0.5 mV rms and
3 mV p-p
Normal mode current <2 mA rms
Common mode current <1.5 uA rms
Load Regulation,
±(% of output + offset)
Voltage <0.01% + 2 mV
Current
<0.01% + 250 μA
Line Regulation,
±(% of output + offset)
Voltage <0.01% + 2 mV
Current <0.01% + 250 μA
Programming Resolution Voltage 1 mV 3 mV
Current 1 mA 0.5 mA
Readback Resolution Voltage 0.5mV 1.5 mV
Current 1 mA 0.5 mA
Front Panel Resolution Voltage 1 mV
Current 1 mA (< 10A), 10mA (. 10A)
