Initial Operation 2
Keysight E3633A and E3634A User’s Guide 41
Power-on Checkout
The power-on test includes an automatic self-test that checks the internal
microprocessors and allows the user visually to check the display. You will
observe the following sequence on the display after pressing the front panel
power switch to on.
1 The front-panel display will light up briefly while the instrument performs
its power-on self-test.
To review the power-on display with all annunciators turned on, hold down
key as you turn on the power supply.
2 The GPIB address or RS-232 is also displayed for about one second.
The GPIB address is set to “5” when the power supply is shipped from the
factory for remote interface configuration. If this is not the first time the power
supply is turned on, a different interface (RS-232) or a different GPIB address
may appear. See “Remote Interface Configuration” on page 79 if you need to
change the remote interface configuration.
3The “8V”
[1]
or “25V”
[2]
, “OVP”, “OCP” and “OFF” annunciators are on. All
others are off.
The power supply will go into the power-on / reset state; the output is disabled
(the OFF annunciator turns on); the 8V/20A
[1]
or 25V/7A
[2]
range is selected
(the 8V
[1]
or 25V
[2]
annunciator turns on); and the knob is selected for voltage
control. Notice that the OVP and OCP annunciator also turn on.
ADDR (or RS-232)
[1] For Keysight E3633A Model
[2] For Keysight E3634A Model
